■ Gett g sta ted ■ Getting started
◇This cloning software is designed to perform data
setting and cloning for the IC-F9510 series VHF
P25 TRUNKING MOBILE TRANSCEIVERS.
◇HELP WINDOW: CS-F9010/F9510 has a help
window to describe functions and operation.
■ System requirement
To use this program the following hardware and To use this program, the following hardware and
software are required:
PC
• Microsoft® Windows® 2000/XP or Microsoft®
Windows Vista® is installed.
• USB port
Oth Other item it
Optional OPC-1122U* CLONING CABLE (USB type)
▒ NOTE:
▒ To use the OPC-1862 /1122U, USB type cloning
▒ cable, USB driver installation is necessary. The
▒ driver is supplied with the OPC-1862 /1122U.
▒*The USB driver, supplied with the OPC-1862
▒ /1122U, is not supported for Microsoft®
▒ Windows Vista® (64 bit).
■ Software installation
▒ When installing the software, log in as the
▒ administrator.
Quit all applications when Windows is running. Quit all applications when Windows is running.
Insert the CD into the appropriate CD drive.
Double-click the "Setup.exe" contained in the CD.
The "Welcome to the InstallShield Wizard for CS-
F9010/ F9510" will appear as below. Click [Next>].
62
4-2 Cloning Software CS-F9010/F9510
4-2-1

Basic Setup of Cloning Software

The "User Information window" will appear as
below, then type your name, your company name
and the product ID number with the following
manner. Then click [Next >].
• ID number: 305701-(6 digit serial number)
▒ Please check the serial number on the CD. If you
▒ have obtained the software by the download
▒ service, enter the ID which was provided from the ▒ service enter the ID which was provided from the
▒ distributor.
The "Choose Destination Location" will appear as
below. Then click [Next>] to install the software to
the destination folder. (e.g. C:╲Program
Fil ╲I Files╲Icom╲CS-F9010_F9510) ╲CS F9010 F9510)
• Click [Browse...] to select another destination
folder before clicking [Next >], if desired.
After the installation is completed, the
"InstallShield Wizard Complete" will appear as
below. Then click [Finish].
Eject the CD.
Program group 'CS-F9010_F9510' appears in the
'Programs' folder of the start menu, and 'CS-
F9010_F9510' short cut icon appears on the
desktop screen.
•To uninstall the cloning software, select the
"Control Panel" in the start menu, and click the
"Add or Remove Programs." Then, select the
program group 'Icom CS-F9010/9510' and click
[Remove].
