INSTRUCTION MANUAL
VHF TRANSCEIVER
VHF TRANSCEIVER
VHF TRANSCEIVER
VHF TRANSCEIVER
IC-F9011B/S/T
This device complies with Part 15 of the FCC Rules. Operation is
subject to the condition that this device does not cause harmful
interference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IC-F9011B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Icom IC-F9011B

Summary of Contents for Icom IC-F9011B

  • Page 1 INSTRUCTION MANUAL VHF TRANSCEIVER VHF TRANSCEIVER VHF TRANSCEIVER VHF TRANSCEIVER IC-F9011B/S/T This device complies with Part 15 of the FCC Rules. Operation is subject to the condition that this device does not cause harmful interference.

  • Page 2: Important

    This instruction manual contains important operating instructions The IMBE™ voice coding Technology embodied in this prod- for the IC-F9011B/F9011S/F9011T VHF TRANSCEIVER. uct is protected by intellectual property rights including patent rights, copyrights and trade secrets of Digital Voice Systems, Inc. This voice coding Technology is licensed solely for use within this Communications Equipment.
  • Page 3 FOR CLASS B UNINTENTIONAL RADIATORS This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reason- able protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

  • Page 4: Precaution

    CAUTION: Changes or modifications to this transceiver, not tery pack. expressly approved by Icom Inc., could void your authority to DO NOT operate this transceiver under FCC regulations. push PTT when not actually desiring to transmit.

  • Page 5: Table Of Contents

    TABLE OF CONTENTS IMPORTANT ..................i EXPLICIT DEFINITIONS ..............i ABOUT APCO PROJECT 25 ............i PRECAUTION ................. ii TABLE OF CONTENTS ..............iii 1 ACCESSORIES ..............1–3 I Supplied accessories ............. 1 I Accessory attachments ............1 4 BATTERY CHARGING ............18–20 I Battery charging ..............

  • Page 6: Accessories

    ACCESSORIES I Supplied accessories I Accessory attachments D Flexible antenna The following accessories are supplied: Qty. q Flexible antenna ……………………………………………1 Connect the supplied flexible anten- w Battery pack …………………………………………………1 na to the antenna connector. e Belt clip ………………………………………………………1 r Jack cover (with screws) ………………………………1 set CAUTION! •...
  • Page 7 ACCESSORIES ï Battery pack D Belt clip To attach the battery pack: To attach the belt clip: q Release the battery pack if it is attached. Slide the battery pack in the direction of the arrow (q), then w Slide the belt clip in the direction of the arrow until the belt lock it with the battery release button.
  • Page 8 ACCESSORIES ï Jack cover Attach the jack cover when the optional speaker-microphone is not used. To attach the jack cover: To detach the jack cover: q Insert the jack cover into e Unscrew the screw with a the [SP MIC] connector. phillips screwdriver.

  • Page 9: Panel Description

    PANEL DESCRIPTION PANEL DESCRIPTION PANEL DESCRIPTION PANEL DESCRIPTION Front panel Front panel Front panel Front panel D .EMERGENCY SWITCH D .EMERGENCY SWITCH D .EMERGENCY SWITCH D .EMERGENCY SWITCH Push and hold for a specied period to transmit an emer- Push and hold for a specied period to transmit an emer- Push and hold for a specied period to transmit an emer- Push and hold for a specied period to transmit an emer- gency call.
  • Page 10 PANEL DESCRIPTION PANEL DESCRIPTION PANEL DESCRIPTION PANEL DESCRIPTION I . 10-KEYPAD (IC-F9011T only ) I . 10-KEYPAD (IC-F9011T only ) I . 10-KEYPAD (IC-F9011T only ) I . 10-KEYPAD (IC-F9011T only ) K. PTT SWITCH [PTT] K. PTT SWITCH [PTT] K.

  • Page 11: I Function Display

    PANEL DESCRIPTION I Function display t SCRAMBLER INDICATOR Appears when the voice scrambler function is activated. y BELL INDICATOR Appears/blinks when the specific 2/5-tone/BIIS code is received, according to the pre-programming. u CALL CODE MEMORY INDICATOR Appears when the call code memory is selected. i SCROLL INDICATOR Appears when a received SDM including more than 12 characters is displayed.

  • Page 12: I Programmable Function Keys

    For example, keys. ‘Staff A’ and ‘Staff B’ are assigned into a “Business” zone, Consult your Icom dealer or system operator for details con- and ‘John’ and ‘Cindy’ are assigned into a “Private” zone. cerning your transceivers programming.
  • Page 13 PANEL DESCRIPTION SCAN TAG KEY LOCK KEY Push to add or delete the selected channel to/from the scan Push and hold to electronically lock all programmable keys group. except the following: [Call] (incl. Call A and Call B), [Moni(Audi)] and [Emergency]. PRIORITY CHANNEL KEYS ➥...
  • Page 14 PANEL DESCRIPTION DTMF AUTODIAL KEY SURVEILLANCE KEY ➥ Push to enter the DTMF channel selection mode. Then Push to turn the surveillance function ON or OFF. select the desired DTMF channel using [CH Up]/[CH Down]. When this function is turned ON, the beep is not emitted and ➥...
  • Page 15 PANEL DESCRIPTION VOICE SCRAMBLER FUNCTION Push to toggle the voice scrambler function ON and OFF. COMPANDER KEY Push to toggle the compander function ON and OFF. The compander function reduces noise components from the transmitted audio to provide clear communication. USER SET MODE KEY ➥...
  • Page 16 PANEL DESCRIPTION D For Digital mode operation only INDIVIDUAL KEY ➥ Push to enter the individual ID code selection mode directly. Then select the desired individual ID code using [CH Up]/ [CH Down]. (p. 15) ➥ Push to stop the beep emission when receiving a matched individual ID code.

  • Page 17: Basic Operation

    BASIC OPERATION BASIC OPERATION BASIC OPERATION BASIC OPERATION Turning power ON Turning power ON Turning power ON Turning power ON Channel selection Channel selection Channel selection Channel selection Rotate [VOL] to turn the power ON. Rotate [VOL] to turn the power ON. Rotate [VOL] to turn the power ON.

  • Page 18: I Call Procedure

    BASIC OPERATION I Call procedure I Receiving and transmitting When your system employs tone signaling (excluding CTCSS Receiving: and DTCS), the call procedure may be necessary prior to voice q Rotate [VOL] to turn the power ON. transmission. The tone signalling employed may be a selec- w Push [CH Up] or [CH Down], or rotate [ROTARY SELEC- tive calling system which allows you to call specific station(s) TOR]* to select a channel in sequence.
  • Page 19 BASIC OPERATION D Transmitting notes D TX code channel selection • Transmit inhibit function If the transceiver has [TX Code CH Select] assigned to it, the The transceiver has several inhibit functions which restrict indication can be toggled between the operating channel transmission under the following conditions: number (or name) and TX code channel number (or name).
  • Page 20 BASIC OPERATION D Individual ID code selection D Talkgroup ID code selection (Digital mode operation only) (Digital mode operation only) If the transceiver has [Individual] assigned to it, the indication If the transceiver has [Talkgroup] assigned to it, the indication can be toggled between the operating channel number (or can be toggled between the operating channel number (or name) and Individual ID code (or name).

  • Page 21: I User Set Mode

    BASIC OPERATION User set mode User set mode is accessed at power ON and allows you to Rotate [VOL] to turn the power set seldom-changed settings. In this case you can “cus- OFF to exit set mode. 3 3 3 3 [VOL] [VOL] [VOL]...

  • Page 22: I Scrambler Function

    BASIC OPERATION I Scrambler function The voice scrambler function provides private communication between stations. The frequency inversion type is equipped to all versions. q Push [Scrambler] to turn the scrambler function ON. • “ ” appears. w Push [Scrambler] again to turn the scrambler function OFF.

  • Page 23: Battery Charging

    Charge the specified Icom batteries only. pack must be fully charged for optimum life and operation. Only tested and approved for use with genuine Icom batter- ies. Fire and/or explosion may occur when a third party bat- CAUTION: To avoid damage to the transceiver, turn the tery pack or counterfeit product is charged.

  • Page 24: I Optional Battery Chargers

    BATTERY CHARGING I Optional battery chargers ï AD-110 installation ï Rapid charging with the BC-119N+AD-110 q Install the AD-110 desktop charger adapter into the holder The optional BC-119N provides rapid charging of battery space of the BC-119N/BC-121N. packs. The following items are additionally required. w Connect the plugs of the BC-119N/BC-121N to the AD-110 •...

  • Page 25: Battery Charging

    BATTERY CHARGING ï Rapid charging with the BC-121N+AD-100 IMPORTANT!: Battery charging The optional BC-121N allows up to 6 battery packs to be Ensure the guide lobs on the battery pack are correctly charged simultaneously. The following items are additionally aligned with the guide rails inside the charger adapter. required.

  • Page 26: Optional Battery Case

    OPTIONAL BATTERY CASE I Optional battery case When using the optional battery case attached to the trans- Fig.1 × AA (LR6) size alkaline batteries as illustrated Latch ceiver, install 6 BP-237 at right. The BP-237 meets JIS waterproof specification grade q Hook your finger under the latch, and open the cover in the direction of the arrow (q).

  • Page 27: Speaker-Microphone

    SPEAKER-MICROPHONE I Optional HM-184 description I Attachment Attach the connector of the speaker-microphone into the [SP/MIC] connector on the transceiver and tighten the screw. CAUTION: Attach the speaker-microphone s connector securely to prevent accidental NEVER immerse the connector in water. If the connector dropping, or water intru- becomes wet, be sure to dry it BEFORE attaching it to the sion in the connector.

  • Page 28: Options

    OPTIONS D BATTERY PACK D BELT CLIPS • BP-254 Li-Ion BATTERY PACK 7.4 V/3040 mAh Li-Ion battery pack, allows more than 8 • MB-115 BELT CLIP hours operation. The same as supplied with the transceiver. Exclusive alligator-type belt clip. The same as supplied with the transceiver.

  • Page 29: Options

    OPTIONS D OTHER OPTIONS • HM-184 SPEAKER MICROPHONE Full-sized waterproof (JIS grade 7; 1m/30 min.) speaker- microphone including alligator type clip to attach to your shirt or collar, etc. • FA-S25V/FA-S65V/FA-S66V FLEXIBLE ANTENNAS FA-S25V: 136–148 MHz FA-S65V: 148–160 MHz FA-S66V: 160–174 MHz •...

  • Page 30: Safety Training Information

    • ALWAYS keep the antenna at least 2.5 cm (1 inch) away IEEE Standard for Safety Levels with Respect to Human from the body when transmitting and only use the Icom Exposure to Radio Frequency Electromagnetic Fields, 3 belt-clips listed on page 39 when attaching the radio to kHz to 300 GHz.
  • Page 31 SAFETY TRAINING INFORMATION Electromagnetic Interference/Compatibility During transmissions, your Icom radio generates RF energy that can possibly cause interference with other devices or systems. To avoid such interference, turn off the radio in areas where signs are posted to do so. DO NOT operate the transmitter in areas that are sensitive to electromagnetic radi- ation such as hospitals, aircraft, and blasting sites.
  • Page 32 A-6418D-1US Printed in Japan 1-1-32 Kamiminami, Hirano-ku, Osaka 547-0003, Japan © 2008 Icom Inc.
