Programmable function keys P g bl f
The following functions can be assigned to [UP],
[DOWN], [P0], [P1], [P2], [P3] and [P4]
programmable function keys. Consult your Icom
dealer or system operator for details concerning
your transceivers programming.
If the programmable function names are bracketed p g
in the following explanations, the specific key is used
to activate the function depends on the
programming.
CH UP AND DOWN KEYS
➥ Push to select an operating channel.
➥ Push to select a scan group after pushing and
holding [Scan A Start/Stop]/[Scan B Start/Stop]. holding [Scan A Start/Stop]/[Scan B Start/Stop]
ZONE KEY
Push this key, then push [CH Up] or [CH Down] to
select the desired zone.
▒ What is "zone"?—The desired channels are
▒ assigned to a zone according to the
▒ intended use for grouping. For example, 'Staff A' ▒ i t d d f g
▒ and 'Staff B' are assigned into a "Business" zone,
▒ and 'John' and 'Cindy' are assigned to a "Private"
▒ zone.
SCAN A START/STOP KEY
➥ Push to start and cancel scanning operation.
• When Power ON Scan function is activated,
push to pause the scanning operation. And
the paused scan resumes after the
specified time period has passed.
➥ Push and hold this key for 1 sec to indicate
the scan list, then push [CH Up] or [CH
Down] to select the desired list. (Available
depending on the pre-set value.)
SCAN B START/STOP KEY
➥ Push to start and cancel scanning operation.
The scan restarts after the specified time
period has passed when the scan (started
with this key) is cancelled by except for this
key operation.
➥ Push and hold this key for 1 sec to display
the scan list, then push [CH Up] or [CH the scan list then push [CH Up] or [CH
Down] to select the desired list.
32
4-1-6 Programmable Function Keys
IC-F9511HT
ti k
i g F l 'St ff A'
SCAN ADD/DEL (TAG) KEY SCAN ADD/DEL (TAG) KEY
Push to add or delete the selected channel to/from
the scan list.
1 Push to display the scan list, then push [CH Up]
or [CH Down] to select the desired list.
2 Push to add or delete the channel to/from the
selected scan list.
3 Push and hold for 1 sec to exit the scan list
selection mode. l ti d
PRIO A/B KEYS
➥ Push to select Priority A or Priority B channel.
➥ Push and hold [Prio A (Rewrite)] or [Prio B
(Rewrite)] for 1 sec to rewrite the operating
channel as the Priority A or Priority B channel.
MR-CH 1/2/3/4 KEYS
Push to select the memory channel 1 to 4 directly.
MONI KEY
Mute and release the CTCSS (DTCS), NAC or
Talkgroup ID squelch mute. Open any
squelch/deactivate any mute while pushing this key.
TALK AROUND KEY (Conventional operation only)
Turn the talk around function ON and OFF.
• The talk around function equalizes the transmit
frequency to the receive frequency for transceiver-
to-transceiver communication.
PUBLIC ADDRESS KEY
Push to activate the Public Address (PA) function for Push to activate the Public Address (PA) function for
voice amplification. When the PA function is
activated, the audio output can be controlled from
the transceiver separately with [CH Up] or [CH Down].
• This function is available when the external unit,
such as a audio amplifier, speaker, etc. is
additionally connected.
• Push this key, then speak into the microphone
while pushing and holding [PTT]. hil hi d h ldi
▒ NOTE: "PA/RX Speaker" setting should be turned
▒ OFF by your dealer with the CS-F9010/F9510
▒ cloning software to activate the PA function.
[PTT]
