INSTRUCTION MANUAL
VHF P25 TRUNKING
HANDHELD TRANSCEIVERS
iF9011B/S/T
UHF P25 TRUNKING
HANDHELD TRANSCEIVERS
iF9021B/S/T
iF9023B/S/T
The photo shows the 10-key
type VHF transceiver.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IC-F9011B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Icom IC-F9011B

Summary of Contents for Icom IC-F9011B

  • Page 1 INSTRUCTION MANUAL VHF P25 TRUNKING HANDHELD TRANSCEIVERS iF9011B/S/T UHF P25 TRUNKING HANDHELD TRANSCEIVERS iF9021B/S/T iF9023B/S/T The photo shows the 10-key type VHF transceiver.

  • Page 2: Explicit Definitions

    Please consult with your dealer or sales representative for details. Icom, Icom Inc. and the Icom logo are registered trademarks of Icom Incor- porated (Japan) in the United States, the United Kingdom, Germany, France, Spain, Russia and/or other countries.

  • Page 3: Fcc Information

    FCC INFORMATION ABOUT IPR • FOR CLASS B UNINTENTIONAL RADIATORS: This device is made under license under one or more of the This equipment has been tested and found to comply with following U.S. Patents: #4,590,473; #4,636,791; #5,148,482; the limits for a Class B digital device, pursuant to part 15 of #5,185,796;...

  • Page 4: Precautions

    CAUTION! Changes or modifications to this transceiver, not DO NOT use or place the transceiver in direct sunlight or expressly approved by Icom Inc., could void your authority to in areas with temperatures below –30°C (+22°F) or above operate this transceiver under FCC regulations.

  • Page 5: Table Of Contents

    TABLE OF CONTENTS IMPORTANT ................i 4 BATTERY CHARGING ..........17−20 EXPLICIT DEFINITIONS ............i ■ Caution ...............17 FCC INFORMATION ............ii ■ Optional battery chargers ...........19 ABOUT IPR ................ii 5 BATTERY CASE ............21 VOICE CODING TECHNOLOGY ......... ii ■ Optional battery case (BP-237) ........21 PRECAUTIONS ..............

  • Page 6: Accessories

    ACCESSORIES ■ Supplied accessories D Battery pack To attach the battery pack: The following accessories are supplied. Slide the battery pack on the back of the transceiver in the direc- tion of the arrow (q), then lock it with the battery release button. Battery pack Flexible •...
  • Page 7 ACCESSORIES D Belt clip D Connector cover To attach the belt clip: Attach the connector cover when the optional equipment is q Release the battery pack if it is attached. not used. w Slide the belt clip in the direction of the arrow until the belt To attach the connector cover: clip is locked and makes a ‘click’...

  • Page 8: Panel Description

    PANEL DESCRIPTION ■ Front panel e LED INDICATOR ➥ Lights green while receiving a signal, or when the squelch is open. ➥ Lights red while transmitting. ➥ The LED indicator indicates some information. (Non dis- play type only) (p. 16) r DEALER-PROGRAMMABLE ABC SWITCH Speaker Desired function can be programmed to each position...
  • Page 9 PANEL DESCRIPTION t CHANNEL INDICATOR !1 10-KEYPAD (10-key type only) ➥ Lights white according to the “Backlight” setting of the The keypad allows you to enter digits to: user set mode. • Select memory channels, tone channels and DTMF codes (while in the DTMF code channel selection mode.) ➥...

  • Page 10: Function Display (Simple/10-Key Types Only)

    PANEL DESCRIPTION ■ Function display (Simple/10-key types only) t SCRAMBLER INDICATOR Appears when the voice scrambler or encryption function is activated. y BELL INDICATOR 001 ch-01 Appears/blinks when the specific page call* is received, according to the pre-programming. * P25 operation only. IC-F9011 u TELEPHONE INDICATOR Appears when a phone call* is received.

  • Page 11: Programmable Function Keys

    *Simple/10-key types only Indicate the programmed function of the front panel keys ([I], [II] and [III]). Consult your Icom dealer or system operator for details con- cerning your transceiver’s programming. See the operating guide for details of Analog and P25 Trunking/Conventional system operations.
  • Page 12 PANEL DESCRIPTION D For All types (Common operation) SURVEILLANCE KEY “SURV” PRIO A AND PRIO B KEYS “PRA” “PRB” Push to turn the surveillance function ON and OFF. Push to select Priority A or Priority B channel. When this function is turned ON, the beep is not emitted and the LCD backlight does not light when a signal is received or MR-CH 1, MR-CH 2, MR-CH 3 AND MR-CH 4 KEYS a key is pushed, etc.
  • Page 13 PANEL DESCRIPTION D For All types (Different operation with Non display type) SCAN B KEY “SCNB” When the following key functions are programmed to Non ❍ For Simple/10-key types display type, the key functions may be limited and some key ➥...
  • Page 14 PANEL DESCRIPTION PRIO A REWRITE AND PRIO B REWRITE KEYS D For Simple/10-key types only “PRAR” “PRBR” Following key functions cannot be programmed to Non dis- ❍ For Simple/10-key types play type. ➥ Push to select Priority A or Priority B channel. ➥...
  • Page 15 PANEL DESCRIPTION MENU AND MENU ➤ KEYS CLOCK KEY “CLCK” ] and [Menu ➤] can only be assigned to [Ω] and ( [Menu Push to indicate the current time on the LCD. (p. 15) [≈], respectively.) • While the current time is indicated, push and hold this key for The menu mode is available when either [Menu ] or 1 sec.
  • Page 16 PANEL DESCRIPTION D For ABC and Toggle switches only ZONE SWITCH SURVEILLANCE SWITCH Selects the pre-programmed zone directly. Turns the surveillance function ON or OFF. When this function is turned ON, the beep is not emitted and the LCD backlight does not light when a signal is received or PRIO A AND PRIO B SWITCHES a key is pushed, etc.

  • Page 17: Basic Operation

    BASIC OPERATION ■ Turning power ON ■ Channel selection • Prior to using the transceiver for the first time, the battery Several types of channel selections are available. Methods pack must be fully charged for optimum life and opera- may differ according to your system set up. tion.

  • Page 18: Receiving And Transmitting

    BASIC OPERATION ■ Receiving and transmitting D Transmitting notes NOTE: Transmitting without an antenna may damage the transceiver. See p. 1 for accessory attachments. • Transmit inhibit function The transceiver has several inhibit functions which restrict Receiving: transmission under the following conditions: q Rotate [VOL] to turn the power ON.

  • Page 19: User Set Mode

    BASIC OPERATION ■ User set mode e Push [Ω] several times to select The user set mode is accessed at power ON and allows you the appropriate item. to set seldom-changed settings. You can “customize” the trans- Then push [∫] or [√] to set the ceiver operation to suit your preferences and operating style.

  • Page 20: Clock Function

    BASIC OPERATION ■ Clock function D Time and date settings The transceiver indicates the current time and date when [Clock] is pushed. And you can change the indication format q Push [Clock] to indicate the current time and date on the and time/date settings.

  • Page 21: Led Indicator (Non Display Type Only)

    BASIC OPERATION ■ LED indicator (Non display type only) The LED indicator indicates some information as follows; r Push [CH Up] or [CH Down] to set the selected item. (Ref.; R=Red, G=Green, O=Orange) • TX: Lights Red while transmitting a signal. 12HR 03:00PM •...

  • Page 22: Battery Charging

    • R DANGER! Use and charge only specified Icom battery • R DANGER! DO NOT expose the battery to rain, snow, packs with Icom radios or Icom chargers. Only Icom bat- seawater, or any other liquids.
  • Page 23 If • R DANGER! NEVER charge the battery pack in areas with any of these conditions occur, contact your Icom dealer or extremely high temperatures, such as near fires or stoves, distributor.

  • Page 24: Optional Battery Chargers

    BATTERY CHARGING ■ Optional battery chargers D Rapid charging with the BC-119N+AD-110 D AD-110 installation The optional BC-119N provides rapid charging of the Li-Ion The AD-110 must be installed into the BC- charger adapter battery pack. Charging period: Approx. 4 hours (with BP-254) 119N or BC-121N before battery charging.
  • Page 25 BATTERY CHARGING D Rapid charging with the BC-121N+AD-110 IMPORTANT: Battery charging caution Ensure the guide lobes on the battery pack are correctly The optional BC-121N allows up to 6 battery packs to be aligned with the guide rails inside the charger adapter. charged simultaneously.

  • Page 26: Battery Case

    BATTERY CASE ■ Optional battery case (BP-237) The optional battery case uses 6 × AA (LR6) size alkaline Fig.1 Latch BP-237 batteries. The battery case offers low output power. q Hook your finger under the latch, and open the cover in the direction of the arrow (q).

  • Page 27: Speaker Microphone

    SPEAKER MICROPHONE ■ Optional HM-184 description ■ To attach Attach the connector of the speaker-microphone into the Microphone multi connector on the transceiver and tighten the screw with a coin or flat head screwdriver. Speaker Belt clip PTT SWITCH Push and hold to transmit;...

  • Page 28: Options

    OPTIONS D BATTERY PACKS D CABLES • CP-17L cigarette lighter cable Battery pack Voltage Capacity Battery life* Allows charging of the battery pack through a 12 V cigarette 2900 mAh (min.) lighter socket. (For BC-119N) BP-254* 7.4 V 9.5 hrs. 3040 mAh (typ.) •...
  • Page 29 Icom optional equipment is designed for optimal perform- ance when used with this transceiver. We are not respon- sible for the transceiver being damaged or any accident caused when using non-Icom optional equipment.

  • Page 30: Safety Training Information

    FCC RF exposure limits. A proper antenna is the antenna This radio has been tested and complies with the FCC RF ex- supplied with this radio by Icom Inc. or antenna specifically posure limits for “Occupational Use Only”. In addition, your Icom authorized by Icom Inc.
  • Page 31 SAFETY TRAINING INFORMATION Electromagnetic Interference/Compatibility During transmissions, your Icom radio generates RF energy that could possible cause interference with other devices or systems. To avoid such interference, turn off the radio in areas where signs are posted to do so. DO NOT operate the transmitter in areas that are sensitive to electromagnetic radiation such as hospitals, aircraft, and blasting sites.
  • Page 32 A-6662D-1US-e Printed in Japan © 2008−2009 Icom Inc. 1-1-32 Kamiminami, Hirano-ku, Osaka 547-0003, Japan Printed on recycled paper with soy ink.
