- Page 1 INSTRUCTION MANUAL VHF P25 TRUNKING HANDHELD TRANSCEIVERS iF9011S iF9011T The photo shows the 10-key version transceiver.
-
Page 2: Explicit Definitions
Trunking/Conventional system operations. Consult your is installed: unit Icom dealer or system operator for details concerning If re-exporting this product and/or AES encryption of this your transceivers programming. product is activated, you must comply with the export regula- tions of your country, which can be highly restrictive. -
Page 3: Fcc Information
FCC INFORMATION ABOUT IPR • FOR CLASS B UNINTENTIONAL RADIATORS: This device is made under license under one or more of the This equipment has been tested and found to comply with following U.S. Patents: #4,590,473; #4,636,791; #5,148,482; the limits for a Class B digital device, pursuant to part 15 of #5,185,796;... -
Page 4: Precautions
CAUTION! Changes or modifications to this transceiver, not DO NOT use or place the transceiver in direct sunlight or expressly approved by Icom Inc., could void your authority to in areas with temperatures below +22°F (–30°C) or above operate this transceiver under FCC regulations. -
Page 5: Table Of Contents
TABLE OF CONTENTS IMPORTANT ................i 4 BATTERY CHARGING ..........17–20 EXPLICIT DEFINITIONS ............i ■ Caution ...............17 FCC INFORMATION ............ii ■ Optional battery chargers ...........19 ABOUT IPR ................ii 5 BATTERY CASE ............21 VOICE CODING TECHNOLOGY ......... ii ■ Optional battery case (BP-237) ........21 PRECAUTIONS .............. -
Page 6: Accessories
ACCESSORIES ■ Supplied accessories ■ Accessory attachments D Flexible antenna The following accessories are supplied. Connect the supplied flexible antenna to the antenna connector. Flexible Battery pack Belt clip antenna CAUTION! • NEVER HOLD the antenna when carrying the transceiver. •... -
Page 7: D Battery Pack
ACCESSORIES D Battery pack D Belt clip To attach the belt clip: To attach the battery pack: q Release the battery pack if it is attached. Slide the battery pack on the back of the transceiver in the direc- w Slide the belt clip in the direction of the arrow until the belt tion of the arrow (q), then lock it with the battery release button. -
Page 8: Accessories
ACCESSORIES D Connector cover Attach the connector cover when the optional equipment is not used. To attach the connector cover: To detach the connector cover: q Insert the connector cover into the multi-connector. q Unscrew the screw using a phillips screwdriver. w Tighten the screw. -
Page 9: Panel Description
PANEL DESCRIPTION ■ Front panel r DEALER-PROGRAMMABLE ABC SWITCH Desired function can be programmed to each position (A, B or C) independently by your dealer. (p. 10) To activate the pre-programmed function, set the white line of the ABC switch to the position A, B or C. White line Speaker Microphone... - Page 10 PANEL DESCRIPTION ■ Front panel (Continued) y DEALER-PROGRAMMABLE TOGGLE SWITCH !2 HOME KEY [HOME] Desired function can be programmed by your dealer. Desired function can be programmed by your dealer. (p. 7) • [Home] is pre-programmed as default. (See page 10 for de- (p.
-
Page 11: Function Display
PANEL DESCRIPTION ■ Function display t SCRAMBLER INDICATOR Appears when the voice scrambler or encryption function is activated. y BELL INDICATOR 001 ch-01 Appears/blinks when the specific page call* is received, according to the pre-programming. * P25 operation only. IC-F9011 u TELEPHONE INDICATOR Appears when a phone call* is received. -
Page 12: Programmable Function Keys
[APP], [HOME], ABC switch and Toggle switch. Indicate the programmed function of the front panel keys ([I], [II] and [III]). Consult your Icom dealer or system operator for details con- cerning your transceiver’s programming. See the operating guide for details of Analog and P25 Trunking/Conventional system operations. - Page 13 PANEL DESCRIPTION ZONE KEY “ZONE” SCAN ADD/DEL (TAG) KEY “SCAD” Push this key, then push [CH Up] or [CH Down] to select the Push to add or delete the selected channel to/from the scan desired zone. list. When [Rotary selector] selects “operating zone,” push this 1.
- Page 14 PANEL DESCRIPTION TALK AROUND KEY “TA” (Conventional operation only) COMPANDER KEY “COMP” Push to turn the talk around function ON and OFF. Push to toggle the compander function ON and OFF. • The talk around function equalizes the transmit frequency to the The compander function reduces noise components from receive frequency for transceiver-to-transceiver communication.
- Page 15 PANEL DESCRIPTION D For ABC and Toggle switches only HOME KEY “HOME” Push to return to the stand-by mode. ZONE SWITCH • After editing some information that requires to be memorized, push Selects the pre-programmed zone directly. this key to save the editing contents in the memory before returning to the stand-by mode.
-
Page 16: Panel Description
PANEL DESCRIPTION HIGH/LOW SWITCH Selects the transmit output power temporarily. • Ask your dealer for the output power level for each selection. SURVEILLANCE SWITCH Turns the surveillance function ON or OFF. When this function is turned ON, the beep is not emitted and the LCD backlight does not light when a signal is received or a key is pushed, etc. -
Page 17: Basic Operation
BASIC OPERATION ■ Turning power ON ■ Channel selection • Prior to using the transceiver for the first time, the battery Several types of channel selections are available. Methods pack must be fully charged for optimum life and opera- may differ according to your system set up. tion. -
Page 18: Receiving And Transmitting
BASIC OPERATION ■ Receiving and transmitting D Transmitting notes NOTE: Transmitting without an antenna may damage the transceiver. See page 1 for accessory attachments. • Transmit inhibit function The transceiver has several inhibit functions which restrict Receiving: transmission under the following conditions: q Rotate [VOL] to turn the power ON. -
Page 19: User Set Mode
BASIC OPERATION ■ User set mode e Push [Ω] several times to select The user set mode is accessed at power ON and allows you the appropriate item. to set seldom-changed settings. You can “customize” the trans- Then push [∫] or [√] to set the ceiver operation to suit your preferences and operating style. -
Page 20: Clock Function
BASIC OPERATION ■ Clock function D Time and date settings The transceiver indicates the current time and date when [Clock] is pushed. And you can change the indication format q Push [Clock] to indicate the current time and date on the and time/date settings. - Page 21 BASIC OPERATION r Push [CH Up] or [CH Down] to set the selected item. 12HR 03:00PM YMD 08-04-01 MUTE CLOCK ZONE t Push [Clock] to set. • The next item blinks. 12HR 03:00PM YMD 08-04-01 MUTE CLOCK ZONE y Repeat steps e to t to set items. u After setting, push and hold [Clock] for 1 sec.
-
Page 22: Battery Charging
• R DANGER! Use and charge only specified Icom battery • R DANGER! DO NOT expose the battery to rain, snow, packs with Icom radios or Icom chargers. Only Icom bat- seawater, or any other liquids. - Page 23 If • R DANGER! NEVER charge the battery pack in areas with any of these conditions occur, contact your Icom dealer or extremely high temperatures, such as near fires or stoves, distributor.
-
Page 24: Optional Battery Chargers
BATTERY CHARGING ■ Optional battery chargers D Rapid charging with the BC-119N+AD-110 D AD-110 installation The optional BC-119N provides rapid charging of the Li-Ion The AD-110 must be installed into the BC- charger adapter battery pack. Charging period: Approx. 4 hours (with BP-254) 119N or BC-121N before battery charging. - Page 25 BATTERY CHARGING D Rapid charging with the BC-121N+AD-110 IMPORTANT: Battery charging caution Ensure the guide lobes on the battery pack are correctly The optional BC-121N allows up to 6 battery packs to be aligned with the guide rails inside the charger adapter. charged simultaneously.
-
Page 26: Battery Case
BATTERY CASE ■ Optional battery case (BP-237) The optional battery case uses 6 × AA (LR6) size alkaline Fig.1 Latch BP-237 batteries. The battery case offers low output power. q Hook your finger under the latch, and open the cover in the direction of the arrow (q). -
Page 27: Speaker Microphone
SPEAKER MICROPHONE ■ Optional HM-184 description ■ To attach Attach the connector of the speaker-microphone into the Microphone multi connector on the transceiver and tighten the screw with a coin or flat head screwdriver. Speaker Belt clip PTT SWITCH Push and hold to transmit;... -
Page 28: Options
OPTIONS D BATTERY PACKS D CABLES • CP-17L cigarette lighter cable Battery pack Voltage Capacity Battery life* Allows charging of the battery pack through a 12 V cigarette BP-254* 7.4 V 3040 mAh 9.5 hrs. lighter socket. (For BC-119N) Battery case for •... - Page 29 Icom optional equipment is designed for optimal perform- ance when used with this transceiver. We are not respon- sible for the transceiver being damaged or any accident caused when using non-Icom optional equipment.
-
Page 30: Safety Training Information
• ALWAYS keep the antenna at least 2.5 cm (1 inch) away Standard for Safety Levels with Respect to Human Exposure from the body when transmitting and only use the Icom belt- to Radio Frequency Electromagnetic Fields, 3 kHz to 300 clips listed on page 24 when attaching the radio to your belt, GHz. - Page 31 SAFETY TRAINING INFORMATION Electromagnetic Interference/Compatibility During transmissions, your Icom radio generates RF energy that could possible cause interference with other devices or systems. To avoid such interference, turn off the radio in areas where signs are posted to do so. DO NOT operate the transmitter in areas that are sensitive to electromagnetic radiation such as hospitals, aircraft, and blasting sites.
- Page 32 A-6662D-1US-q Printed in Japan © 2008 Icom Inc. 1-1-32 Kamiminami, Hirano-ku, Osaka 547-0003, Japan Printed on recycled paper with soy ink.
