Large Disk Access Mode: options include
if you are using DOS or one of the DOS-based operating
DOS
systems. Select
Other
such as UNIX. A large disk is considered one that has more than
1024 cylinders, 16 heads or 63 tracks per sector.
•
Resource Configuration opens the Resource Configuration
screen. Details of this screen are provided in the following section,
"Resource Configuration screen" on page 62.
•
Peripheral Configuration opens the Peripheral Configuration
screen. Details of this screen are provided in the following section,
"Peripheral Configuration screen" on page 65.
•
Keyboard Features opens the Keyboard Configuration screen.
Details of this screen are provided in the section "Keyboard
Features screen" on page 67.
•
Cache Memory opens the Cache Memory Configuration screen.
Details of this screen are provided in the section "Cache Memory
screen" on page 68.
•
Advanced Chipset Control opens the advanced chipset control
screen which contains a single field. The field is
allows you to set the extent of error checking and correction that
the system uses. The options for this field are
ECC Scrub.
•
Embedded PCI SCSI: Channel A enabling turns on channel A
of the optional integrated SCSI adapter. The Scan First option is set
if booting from a hard disk and the Scan Last option is selected if
booting from a CD-ROM. The options are
•
Embedded PCI SCSI: Channel B enabling turns on channel B of
the optional integrated SCSI adapter. The Scan First option is set if
booting from a hard disk and the Scan Last option is selected if
booting from a CD-ROM. The options are
•
Embedded PCI NIC: enabling turns on the optional integrated
Network Interface Connection. The options are
Disabled.
•
SHM Address: defines the System Hardware Manager (SHM)
address. The options are 1 through 7 (Note: always 1 in stand-alone
configurations).
if you are using another operating system
Enabled
Enabled
and
. Select
DOS
Other
which
ECC Config,
and
Disabled, EC, ECC,
and
.
Disabled
and
.
Disabled
and
Enabled
BIOS Setup
61
