IDE Removable - Select this option of the drive is a
removable disk drive.
•
ATAPI Removable - Select this option if the drive is an
ATAPI removable disk drive.
•
None - "Auto" has been unable to supply the drive type or
select "None" to disable any drive installed.
•
Multi-Sector Transfers: enabling this option allows multiple
sector data transfers on compatible drives. The options are
DISABLED, STANDARD, 2 SECTORS, 4 SECTORS, 8 SECTORS,
16 SECTORS.
•
LBA Mode Control: enabling this option causes Logical Block
Addressing to be used in place of Cylinders, Heads and Sectors.
The options are
ENABLED
•
32 Bit I/O: enabling this option allows 32-bit communication
between the CPU and the IDE controller. The options are
and
DISABLED.
•
Transfer Mode: selects the method for moving data to and from
the drive. The options listed are those supported by the drive and
the platform; either
or
FAST PIO 4;
STANDARD, FAST DMA A, FAST DMA B,
•
Ultra DMA Mode: enabling this option allows a faster data
transfer rate with compatible drives. The options are
DISABLED.
and
DISABLED.
STANDARD, FAST PIO 1, FAST PIO 2, FAST PIO 3,
and
ENABLED
and
and
FAST DMA F.
and
ENABLED
BIOS Setup
59
