One VGA video port
•
One PS/2-style mouse port
•
One PS/2-style keyboard port
•
One RJ-45 Ethernet connector with two LED indicators. The green
LED indicates a communication link has been established with the
network and the yellow indicator shows that the communication is
occurring at 100 Mbps when on and at 10Mbps when off.

Processor subsystem

The system board supports as many as two processors (CPUs). The board
provides several additional connectors for supporting components, as
described in the following paragraphs.
CPUs and CPU slots
Depending on the model, the system is equipped with one Intel Pentium
processor with 512-KB ECC L2 cache integrated into a Single Edge
Contact (SEC) cartridge.
The system's SMP design supports up to two processors and is Intel MP
Specification v1.1 and 1.4 compliant.
CPU fan connectors
The CPU fan connectors provide power for the fans mounted on the
processor heatsinks. These fans cool the processors and prevent
overheating. Note that not all processor heatsink have or need fans. If the
processor heatsink includes a fan, connect it to the correct fan connector.
®
