Picture 4: Transport lock

Picture 5:
Removing transport lock
Important: Keep the transport lock, the washers as well as the adherent label for future
use. The transport lock and the washers must be inserted before every
transport of the WideTEK A2. This will prevent the sensitive components
inside the flatbed scanner against damages.
Page 16
The transport locks are marked with adherent
labels.
If the scanner is placed on the small back side, the
transport locks are easily accessible.
Remove the transport lock with an appropriate tool.
