- Page 1 Operation Manual...
-
Page 2: Table Of Content, Part
File: WT36C_WT48C_OperationManual-D2.docx... -
Page 3: Table Of Content, Part
Image Access. All other trademarks are the property of their respective owners. Image Access reserves the right to change the described products, the specifications or documents at any time without prior notice. For the most recent version, always check our web site www.imageaccess.de... -
Page 4: Introduction
The Image Access team congratulates you on the acquisition of this innovative large format scanner. We at Image Access are proud of the work we do; it is the result of our extremely high standards of production and stringent quality control. -
Page 5: About This Manual
About this Manual Operation Manual The Operation Manual gives all information about the normal operation and behavior of the device. It is written for people who only operate the device and do not perform setup and adjustment procedures. All device elements and software functions are described in detail, although some of them might never be used. -
Page 6: Version History
Version History Version Published in Content/Changes/Supplements May 2011 Preliminary version. July 2011 Information after EMC and safety testing and certification added. September 2011 Chapter C.3.9: New content, former chapter C.3.9 renumbered to C.3.10. Content of chapter C.5.2 revised, new screenshots added. October 2011 Chapter B.6.3.1 added. -
Page 7: Table Of Contents
Table of Content Introduction -------------------------------------------------------------------------- 4 About this Manual ----------------------------------------------------------------- 5 Version History --------------------------------------------------------------------- 6 A Hardware ----------------------------------------------------------------------- 14 Safety Notes ...................... 14 A.1.1 Marking of Safety Notes Certification ......................14 General Notice ....................14 Safety Precautions ..................... 15 Device Location....................16 Maintenance ...................... - Page 8 Table of Content, part 2 B Touchscreen Operation --------------------------------------------------- 28 Select Application ....................28 B.1.1 Document Transport Window The Kiosk User Interface ................... 30 B.2.1 Control Fields of the Touchscreen Touchscreen – Document Source ..............32 B.3.1 B.3.2 Transport Speed B.3.3 Exposure B.3.4...
- Page 9 Table of Content, part 3 Touchscreen – Viewer&Job Control ..............45 B.5.1 Zonal OCR B.5.2 Job Mode B.5.2.1 Navigating through the list of images B.5.2.2 Moving an image to another position B.5.2.3 Adding an image at an any position to the list B.5.2.4 Deleting an image from the list B.5.2.5...
- Page 10 Table of Content, part 4 E Tests and Troubleshooting ---------------------------------------------- 79 Troubleshooting Matrix ..................79 F Technical Data ---------------------------------------------------------------- 80 Scanner Specifications ..................80 Electrical Specifications ..................82 Ambient Conditions .................... 83 Dimensions and Weight ..................83 CE Declaration of Conformity ................84 FCC Declaration of Conformity ................
- Page 11 Picture 8: WideTEK 36C Main power switch and connectors ...........22 Picture 9: WideTEK 48C front view ..................23 Picture 10: WideTEK 48C Main power switch and connectors .........23 Picture 11: WideTEK 36C DVI connector .................24 Picture 12: WideTEK 48C DVI connector .................24 Picture 13: Recovery Key connector, covered with plastic cap .........25...
- Page 12 Table of Pictures, part 2 Picture 31: Image Quality 2 ..................... 40 Picture 32: List of Color Modes ..................41 Picture 33: Submenu File Format “jpeg” ................41 Picture 34: Submenu File Format TIFF ................42 Picture 35: Brightness slider .................... 43 Picture 36: Contrast slider ....................
- Page 13 Table of Pictures, part 3 Picture 61: Parameters of Copy Options ................58 Picture 62: Printer settings window ..................58 Picture 63: Parameters of FTP Options................59 Picture 64: Parameters of Network Options ..............60 Picture 65: Parameters of Mail Options ................61 Picture 66: Interactive mode, mail options ................62 Picture 67: Scan2Net®...
-
Page 14: A Hardware
Hardware Safety Notes Read and ensure that you understand the safety notes. They are designed for your protection and for your safety. Follow all safety notes to avoid damage to the device. A.1.1 Marking of Safety Notes All safety notes are marked with a yellow triangle warning sign. Next to the warning sign, you’ll find a description of the danger. -
Page 15: Safety Precautions
12. Always turn the power off and unplug the external power supply before cleaning the scanner. 13. When cleaning, only use Image Access-approved cleaners. Do not use any type of solutions, abrasives, or acids such as acetone, benzene, kerosene, mineral spirits, ammonia, or nitric acid. -
Page 16: Device Location
Device Location The installation location must have — a minimum distance of not less than 150 mm (6 inch) between the sides of the scanner and the wall, — a minimum distance of not less than 300 mm (12 inch) between the backside of the scanner and the wall, —... -
Page 17: Maintenance
Maintenance Important: Ensure that no liquids will penetrate into the device housing. A.6.1 Touchscreen WideTEK® 36C / WideTEK® 48C Before cleaning the touchscreen, switch the off and set the main power switch to position 0. The touchscreen can be cleaned with a micro fiber cloth. A.6.2 Surfaces Use a soft, dampened cloth to clean the housing of the scanner. -
Page 18: Content On Delivery
Content on Delivery WideTEK ® A.8.1 When delivered, the scanner is placed at a Euro pallet, bordered at all sides by a stable wooden frame and covered with a wooden top cover. After removing the top cover of the transport box the paper output tray is visible. E:\Bild\WT_36C\Verpackung\2011_03\ P1060754_a.jpgP1060755_c.jpg 1: Paper output tray... -
Page 19: Picture 3: Parts In The Transport Box
2: Patch cable 3: Foot pedal switch 4: External power supply with power connector cable 5: Floor stand in cardboard Picture 3: Parts in the transport box Take the three parts out of the transport box. Remove the six foam inserts beside the scanner and the cardboard box. The wooden frame will slide down when removing the foam inserts. -
Page 20: Widetek ® 48C
WideTEK ® A.8.2 When delivered, the scanner is placed at a Euro pallet, bordered at all sides by a stable wooden frame and covered with a wooden top cover. After removing the transport box top cover the scanner and all accessories are visible. The WideTEK ®... -
Page 21: Keeping The Transport Box For Later Use
Take the parts out of the transport box. WT48C-300: The box with floor stand is replaced by an empty box. WT48C-300-BDL: Start with paper the output tray, then take out all boxes, the reference folder and the all small accessories. Pull up the foam inserts and remove them. -
Page 22: Device Overview
Device Overview WideTEK ® A.9.1 – Front Side Elements Picture 7: WideTEK 36C front view The main components of the WideTEK ® are: Upper unit. The upper unit contains the cameras and the paper transport. Touchscreen. The touchscreen shows all menus to set up and control the scanner On/Off button. -
Page 23: Widetek ® 48C - Front Side Elements
Seen from the operators view (i.e. from the front of the scanner), the connectors are positioned at the right back side of the housing. Picture 10: WideTEK 48C Main power switch and connectors A label beside the connectors shows and names each connector. -
Page 24: Monitor Connector Widetek 36C
To show previews of the scanned documents an external monitor can be connected to the WideTEK ® 48C. A DVI video connector allows connecting the monitor to the scanner. Picture 12: WideTEK 48C DVI connector Note: Although the scanners receptacle will accept DVI-D, DVI-A and DVI-I plugs, it only supports DVI-D. Valid for both scanner types DVI-I to VGA cables will not work on this connector. -
Page 25: Recovery Key Connector
A.9.7 Recovery Key Connector Seen from the operators view (i.e. from the front of the scanner), the Recovery Key connector is positioned at the left back side of the housing. Picture 13: Recovery Key connector, covered with plastic cap Detailed information about the recovery function can be found in the separate Setup Manual. -
Page 26: Connecting To The Power Source
A.10 Connecting to the Power Source Before connecting the scanner to the external power supply and the power supply to the electrical outlet, check the following items: Ensure the electrical outlet is in perfect condition and that it is properly grounded. Ensure that the electrical outlet is equipped with a fuse with the proper capacity. -
Page 27: Powering Up The Scanner
A.10.1 Powering up the Scanner The main power switch is found at the back of the scanner. Picture 8 resp. Picture 10 show the position of power supply connector and main power switch. After connecting the scanner to the external power supply, switch the main power switch to position I. -
Page 28: B Touchscreen Operation
Touchscreen Operation The scanner can be controlled in two ways. • Via the integrated touchscreen. • Via a standard browser and the ScanWizard user interface. A short introduction of the functions of the integrated ScanWizard user interface starts in chapter C. Please note: All screenshots are taken from a fully equipped device with all options and functions activated. -
Page 29: Document Transport Window
B.1.1 Document Transport Window Touching this button opens the Document Transport window before starting the Kiosk interface. Picture 15: Document Transport Document Output Eject: Transports the document out of the scanner after terminating the scan sequence. Hold: Holds the document after terminating the scan sequence at the output side of the transport path. -
Page 30: The Kiosk User Interface
The Kiosk User Interface After touching the Scan2Net button the Viewer&Job Control screen is displayed on the touchscreen. Picture 16: Viewer & Job Control screen The touchscreen is structured in four sections, which allow operators to control and select various functions of the scanner. This section shows the main controls or parameters depending on the selected control field in section 2. -
Page 31: Control Fields Of The Touchscreen
B.2.1 Control Fields of the Touchscreen By touching the buttons in section 2 each menu screen can be reached directly. The chapters B.3 to B.6 describe the functions of the menus in detail. Touch this button to start the scan sequence. Touch this button to return to the start screen from every other menu. -
Page 32: Touchscreen - Document Source
Touchscreen – Document Source The number of buttons and controllers in each screen can vary depending on the selected setup. The setup can be changed by the administrator in the Poweruser menu. The Document Source screen allows selecting from a wide range of scan parameters. Picture 17: Document Source screen If the content of a screen is too large to be displayed in the touchscreen completely, a scrollbar is displayed at the right side. -
Page 33: Transport Speed
B.3.2 Transport Speed The Transport Speed selector allows the user to select from two speed settings. Picture 19: Available Scan Modes This setting determines the transport speed when feeding a document into the scanner. Normal Transports the document with default speed; recommended for most documents. -
Page 34: Exposure
B.3.3 Exposure The Exposure screen allows selecting the functions Black Cut and Auto. Fixed switches the function off. Picture 20: Exposure Modes When Black Cut or Auto is selected a numeric key pad opens. Picture 21: Numeric key pad to set threshold value Black Cut Sets the threshold for black. -
Page 35: Format
B.3.4 Format The Format button allows selecting the scan area size. Depending on the Document Mode selected, the available formats will vary. The bottom line of the button Format shows the current format setting. Picture 22: Selector for Format settings The following subchapters describe the available combinations of document mode and format. -
Page 36: Auto
B.3.4.2 Auto The complete scan area will be scanned. Picture 24: Format mode Auto The resulting image will be reduced to the document size. If the document is not exactly aligned horizontally, the resulting images will have the smallest possible black margin. The black margin depends on the size of rectangle which covers the complete document. -
Page 37: Din
B.3.4.4 DIN Picture 26: Format mode DIN When selecting DIN, an additional small window opens. It shows the available DIN (=ISO) document sizes as well as 25 inch and 36 inch width as scan area dimension. All formats are positioned symmetrically to the horizontal middle of the document input. B.3.4.5 ANSI Picture 27: Format mode ANSI When selecting ANSI, an additional small window opens. -
Page 38: Scan Mode
B.3.5 Scan Mode The Scan Mode selector allows the user to select between two scan quality settings. Picture 28: Scan Mode selector In general, the scan resolution has always an impact at the scan speed. The higher the resolution, the lower the resulting scan speeds. Fast Scans with normal scan speed, depending from the selected resolution. -
Page 39: Auto Density
B.3.6 Auto Density The Auto Density controller is used to set the scanner’s sensitivity for the automatic format detection. Default value: 60 Picture 29: Auto Density controller When scanning dark documents, the value should be reduced in small steps until the desired result is achieved. -
Page 40: Touchscreen - Image Quality
Touchscreen – Image Quality The Image Quality screen allows setting a wide range of image quality parameters. Picture 30: Image Quality, screen 1 In color mode Binary, the menu will be extended by two more menu items. Picture 31: Image Quality 2 The additional menu items are Invert and Despeckle. -
Page 41: Color Mode
B.4.1 Color Mode By touching the selection arrow of the Color Mode section the list of available color modes opens. Picture 32: List of Color Modes Touch the title of the desired color mode to select the mode. The list closes subsequently. Picture 32 shows the available color modes. -
Page 42: Tiff
B.4.2.2 TIFF Picture 34: Submenu File Format TIFF With the TIFF file format, the compression method of the file can be selected with the TIFF Compression buttons. CCITT G4 Recommended with color mode “Binary”. JPEG Recommended for all other color modes. None Disables the data compression. -
Page 43: Brightness
B.4.3 Brightness Picture 35: Brightness slider The Brightness slider defines the resulting brightness in the image. Lower brightness values result in darker images, higher values result in brighter images. Values close to 0% or to 100% may result in unwanted artifacts. Move the slider indicator to the desired position to set the value. -
Page 44: Image Rotation
B.4.6 Image Rotation Picture 38: Image Rotation The value selected from the list defines the rotation of the image in a clockwise direction. The image will be rotated directly after scanning and before display B.4.7 Mirror Picture 39: Mirror This control mirrors the image along the selected mirror axis. Using this setting can be helpful if scanning transparencies from the back. -
Page 45: Touchscreen - Viewer&Job Control
Touchscreen – Viewer&Job Control The Viewer Control screen allows the operator to control and modify the image on the TFT flat screen. Picture 42: Viewer & Job Control screen The preview section (1) represents the TFT flat screen. The scanned image is displayed on the TFT flat screen and with reduced quality in the preview section right beside the controller elements. - Page 46 The controller is structured in three round elements (circles). The outer circle contains the keys to move the zoomed area across the image. The middle circle contains the keys to zoom in zoom out rotate the image in clockwise direction in steps of 90 degrees scale the image to the real size of the source document.
-
Page 47: Zonal Ocr
B.5.1 Zonal OCR The scanner offers a zonal OCR function. This function can be activated by the button positioned right below the preview section. Zonal OCR means, that only the marked area will be processed by the OCR function. Text and line feed will be found only. -
Page 48: Picture 46: Rectangle Defines The Area For Ocr Function
Touch the image at an arbitrary position. A red rectangle will be displayed. Picture 46: Rectangle defines the area for OCR function Exit: Press Exit to return to the former screen. CUT: Press the CUT button. The next screen will display the defined area more detailed. -
Page 49: Picture 48: Selected Area Magnified
Press CUT to separate the previously defined area from the complete image and to display it in detail. Picture 48: Selected area magnified The next screen shows the selected area magnified and allows again defining an area for the OCR process. Press CLR to return to the former screen and to repeat the definition of the OCR area. -
Page 50: Job Mode
B.5.2 Job Mode The bottom line of the Viewer & Job Control screen is different to the bottom line of the other screens. Picture 50: Bottom line with status The bottom line shows • the current scan mode status, • the button to switch the job mode between Single and Job mode •... -
Page 51: Picture 52: Disclaimer When Staring The Job Mode
When Job mode is selected, the contents of the touchscreen change. At first a disclaimer opens, which has to be accepted. Picture 52: Disclaimer when staring the Job mode After accepting the disclaimer, the Viewer&Job Control screen opens. It contains some additional control buttons above and below the preview section. Picture 53: Job mode start screen Manual Page 51... -
Page 52: Navigating Through The List Of Images
B.5.2.1 Navigating through the list of images The control buttons allow navigation through the list of scanned images and image handling while working in Job mode. The currently scanned image is always displayed in the preview section of the touchscreen and will be added as last image to the list displayed at the TFT flat screen. The control buttons allow moving upwards and/or downwards through the list of images to mark an image or... -
Page 53: Moving An Image To Another Position
B.5.2.2 Moving an image to another position Use the upwards / downwards buttons to mark the image to be moved. Press this button to select the image. The image now can be moved with the upwards / downwards buttons to the new position. Press this button again to place the image at the new position. -
Page 54: Finalizing The Job Mode
B.5.2.6 Finalizing the Job mode Before finalizing the Job mode the scanned images can be transferred to different destinations. Picture 55: Destination to finalize Job mode The destinations are identical to the destinations described in chapter B.6 and its subchapters. Before the Job mode will be finalized, a message is displayed at the touchscreen. -
Page 55: Touchscreen - Send To
Touchscreen – Send To This menu provides five output options in order to store the scanned images. Picture 57: "Send To" screen #1 Due to the dimension of the touchscreen, not all output options can be displayed at the same time. By using the scrollbar at the right side, the content of this menu can be moved. Move the scrollbar down to display the fifth output option on the touchscreen. -
Page 56: Changing A File Name Or Other Entries
B.6.1 Changing a file name or other entries In some of the option menus the file name can be changed. To change the file name, touch the respective line. The screen changes to an alphanumeric keyboard. Picture 59: Alphanumeric keyboard Use the arrow keys to position the cursor in the line. -
Page 57: Usb Options
B.6.2 USB Options Two USB connectors are available at the front of the scanner to connect suitable USB data carriers, for example USB sticks. Touching USB Options displays the directory of a connected USB data carrier. Picture 60: Directory of connected USB data carrier While the directory of the USB data carrier is displayed, the LED indicator of the respective connector is continuously illuminated. -
Page 58: Copy Options
B.6.3 Copy Options Touch Copy Options to switch to the screen with the preset copy option configurations. Three preset options can be stored and activated with the buttons Copy1 to Copy3. Picture 61: Parameters of Copy Options The parameters displayed in the above picture can only be changed from the Scan2Net® setup interface, user level Poweruser. -
Page 59: Ftp Options
B.6.4 FTP Options Touch FTP Options to switch to the screen with the preset FTP server configurations. Three preset FTP servers can be stored and activated with the buttons FTP 1 to FTP 3. Picture 63: Parameters of FTP Options From the touchscreen, only the entry for File Name can be changed. -
Page 60: Network Options
B.6.5 Network Options Touch Network Options to switch to the screen showing the preset network configurations. Three preset configurations can be stored and activated with the buttons Network 1 to Network 3. Picture 64: Parameters of Network Options From the touchscreen, only the entry for File Name can be changed. To change the entry, touch the respective line. -
Page 61: Mail Options
B.6.6 Mail Options Touch Mail Options to switch to the screen showing the preset email configurations. Three preset configurations can be stored and activated with the buttons Mail 1 to Mail 3. Picture 65: Parameters of Mail Options To change an entry, touch the respective line. From the touchscreen the values for •... -
Page 62: Transaction Modes
B.6.6.1 Transaction modes Two transaction modes are available for the mail transfer. The parameters for the transaction modes can be set from the Scan2Net setup interface. The mode, selected in the Scan2Net user interface, influences the process when a scanned image should be mailed. Automatic When pressing the button Mail image via SMTP at the touchscreen, the image will be sent to the address defined in the screen Mail Options... -
Page 63: C Software Operation
Software Operation Essentially, the scanner is a web server and comes with its own HTML based user interface, named ScanWizard. A basic requirement before working with the integrated ScanWizard user interface is to configure the browser as follows: • Force the browser to reload the page content every time directly from the scanner and not to load from the cache memory. -
Page 64: The Scanwizard User Interface
The ScanWizard User Interface After pressing the Launch Scan Application button the browser will show the ScanWizard interface. Picture 68: ScanWizard interface You can bookmark the address of the ScanWizard interface in your browser for easy access later. ScanWizard is a function rich software which allows the user configuring and operating the scanner easily without any additional software. -
Page 65: Online Help
C.1.1 Online Help These tool bars are described in detail in the online help function included in the ScanWizard interface. Click in the “Administration” menu, item “Online Help”. Picture 70: Online Help C.1.2 Exit ScanWizard To exit the ScanWizard interface click on the main menu item “Administration”. Then click on “Exit”. -
Page 66: Information
Information Click on the button Information in the Scan2Net® main menu (Picture 67) to get a short summary of the device parameters. Picture 72: Summary of device parameters The screen is helpful if technical support is necessary. It shows e.g. the exact device type, the installed firmware version as well as currently installed options. -
Page 67: D The Setup Level
The Setup Level The setup level is divided in three access levels. The access levels Poweruser and Admin are password protected. The User access level allows showing certain information about the system like power up time, remaining lamp life time or firmware version. Furthermore the access level User allows setting some basic parameters. -
Page 68: Access Level User
Access Level User Click the button User . This will open the below displayed screen. Picture 74: User screen The user screen is divided into two sections. The section Device Information shows some details of the scanner and gives general operation information. -
Page 69: Device Info Screen
D.1.1 Device Info Screen In the section Device Information click the button Device Info and the following list will be displayed (see Picture 75). Specific information can be reached by clicking the links below the headline Device Info. Picture 75: Device Info screen The table following the respective keyword shows the current status of the scanner. -
Page 70: Picture 76: Firmware Information
The most important information for users is the firmware version in the second table. Picture 76: Firmware information Click on the links to get other information may be of interest if a service technician is onsite or if the service hotline is called. To return to the USER screen (Picture 74), click the button Back to Main Menu or click on the “Return”... -
Page 71: Operation Info Screen
D.1.2 Operation Info Screen Click the button Operation Info to show various scan counters and elapsed times since the first start of the scanner. Picture 77: Operation Info screen The following table gives a brief description. Field Description Total Scan Count The total number of scans performed since the scanner left the factory. -
Page 72: User Settings Screen
D.1.3 User Settings Screen In the section User Settings click the button User Settings and the following screen will be displayed. Picture 78: Start screen User Settings Power Saving screen will be displayed as start screen of the User Settings section. -
Page 73: Language Selector
D.1.3.1 Language Selector Use the function Language Selector to select the language for the setup interface. Picture 79: Language Selector of the setup menu Click at the selection arrow to show the list of available languages. Picture 80: List of languages Select by clicking the desired language from the list. -
Page 74: File Name
D.1.3.2 File Name Use the function File Name to define a default name which is used when saving images after scanning. Picture 81: Filename When defining the default name, variables can be used. To get a list of the variables, click at the link Wildcard characters. -
Page 75: Power Saving
D.1.3.3 Power Saving Use the function Power Saving to set the timers for the standby modes. Three settings can be defined. Click on the link Power Saving. Picture 83: List of power down times The default settings for standby are 15 minutes; the default setting for screen saver is 10 minutes. -
Page 76: Transport Speed
D.1.3.4 Transport Speed Two transport speeds are available. They can be selected in the touchscreen as well as in the ScanWizard interface. Use the function Transport Speed to set the values. Picture 84: Transport speeds Click at the selection arrows to display the speeds available for the setting Slow and Normal. -
Page 77: Volume
D.1.3.5 Volume Click the link Volume to set the loudspeakers volume of the scanner. Picture 85: Volume level A screen opens and shows a graphic to symbolize the volume. Click at the scale to set the volume level or click with the mouse at the arrow and move it to the desired value To return to the Login screen (Picture 73) click the button Setup Menu . -
Page 78: Splitting Start Page
D.1.3.6 Splitting Start Page Click the button Splitting Start Page and select either the left page or the right page as start page. Picture 86: Splitting Start Page In some cases it is necessary to start splitting the documents image in reverse order, i.e. starting with the right side followed by the left side in the second step. -
Page 79: E Tests And Troubleshooting
Tests and Troubleshooting Troubleshooting Matrix Fields with a light blue background need the power user access level. All other fields are available to all users. Problem Possible cause Action Image is darker than The target used for white Go to the Adjustments function and expected. -
Page 80: F Technical Data
Technical Data Differences between the scanners WideTEK ® and WideTEK ® Note: will be marked in the headline of the tables. Scanner Specifications WideTEK ® Optical System Document width 38 inches / 965 mm Scan width 36 inches / 915 mm Maximum document thickness 0.05 inch / 1.5 mm Scan direction... - Page 81 WideTEK ® Optical System Document width 50 inches / 1270 mm Scan width 48 inches / 1219 mm Maximum document thickness 0.05 inch / 1.5 mm Scan direction Face up Scanner resolution 1200 x 1200 dpi Optical resolution 1200 x 600 dpi Pixel dimension 42 x 42 µm Sensor type...
-
Page 82: F.2 Electrical Specifications
Electrical Specifications External Power Supply Voltage 100 – 240 V AC Frequency 47 – 63 Hz Inrush current 120 A max / 264 V AC Efficiency 85 % Operating temperature 5 to 40 °C / 41 to 104 °F Operating humidity 10 …... -
Page 83: F.3 Ambient Conditions
Ambient Conditions Operating temperature 5 to 40 °C / 40 to 105 °F Storage temperature 0° to 60 °C, 32° to 140 °F Relative humidity 20 to 80% (non-condensing) Noise level < 35 dB(A) (Operating) < 25 dB(A) (Standby) Dimensions and Weight WideTEK ®... -
Page 84: F.5 Ce Declaration Of Conformity
Image Access GmbH Hatzfelder Strasse 161 – 163 42281 Wuppertal, Germany herewith declares that the Products: WideTEK 36C / WideTEK 48C Scanner Model Designation: WT36C – XXX / WT48C-XXX XXX represents the device version number and configuration details) Serial number:... - Page 85 EMC: EMC Directive 2004/108/EC as per EN 55022 :2006 + A1 :2007 EN 61000-3-2:2006 + A1 :2009 + A2 :2009 EN 61000-3-3 :2008 EN 55024 :1998 + A1:2001 + A2:2003 EN 61000-4-2:2009 EN 61000-4-3:2006 + A1 :2008 EN 61000-4-4:2004 + A1 :2010 EN 61000-4-5:2006 EN 61000-4-6:2009 EN 61000-4-11:2004...
-
Page 86: F.6 Fcc Declaration Of Conformity
Responsible party: Image Access GmbH Hatzfelder Strasse 161 – 163 42281 Wuppertal, Germany Product: WideTEK 36C / WideTEK 48C Scanner Model Designation: WT 36C-XXX / WT48C-XXX XXX represents the device version number and configuration details) Serial number: This devices comply with FCC, Part 15, Class B and ICES-003. - Page 87 For your notes Manual Page 87...
