B.4.2.6 Maximum Deskew [Angle]
This function is used to modify (deskew) the position of the image of the scanned
document.
Example:
Picture 40: "Deskew" not active
Please note that all changes are immediately valid. That is, new settings and new
values are immediately transferred to the scanner.
Operation Manual
Select Use Deskew
If the angle is set to 0 (zero) the slider is replaced by the
two radio buttons.
Value range from 5 to 40 degree.
Defines the maximum angle for the automatic deskew
function.
In order to define the maximum angle which is corrected,
click onto the slider or enter a value in the field beside
the slider.
Yes to activate this function.
Picture 41: „Deskew" active
Page 45
