4.10 Setting the PAGE LENGTH
This function sets the length of each page when long-axis cutting or plotting is performed using a roll
medium. This should be set for long-axis cutting or plotting exceeding 5 m in length. The default setting is
"5000 mm."
M O V E T O R . M A R K
F E E D
A U T O P R E F E E D
T A N G E N T I A L
A U T O R E G . M A R K
C L E A R B U F F E R
A X I S A L I G N M E N T
D I S T A N C E A D J U S T
P A G E L E N G T H
P L O T A R E A
E X P A N D
R O T A T E
M I R R O R
C O P Y
S O R T
R S - 2 3 2 C
C O M M A N D
B L A D E W E A R S E T U P
P E N U P / D O W N
T E S T M O D E
P E N U P S P E E D
O F F S E T F O R C E
O F F S E T A N G L E
S T E P P A S S
I N I T . D O W N F O R C E
L E N G T H U N I T
CAUTION • In the case of long-axis cutting, be particularly careful when loading color adhesive-
backed film. If the film is loaded at even a slight angle, the film may come loose from
the rollers that hold it in place.
• When using roll media, either extend and load the length to be used beforehand or
use the media feed procedure ("4.3 Setting the FEED function", "4.4 Setting AUTO
PRE-FEED").
Beginning cutting or plotting without feeding the media first may generate a position
error or may cause the roll media to fall off the stock shaft.
1
Step
Press the (PAUSE) key to switch to PAUSE mode.
2
Step
Press the (NEXT) or
P A G E L E N G T H
3
Step
Press the (ENTER) key to display the page-length menu.
L = 0 5 0 0 0 m m
Use the or key to move the cursor to the digit to be changed. Use the
and keys to increase or decrease the setting, and then press the
key to confirm. To cancel, press the
4
Step
Press the (PAUSE) key to cancel PAUSE mode.
CHECKPOINT
• This setting is retained in the memory even when the
• The cutting plotter's distance precision is guaranteed for
(PREV.) key until the following menu is displayed.
(NEXT) or
power is turned off.
page-feed lengths of up to 5 meters, provided that the
following conditions are satisfied. Long-axis cutting over
5 meters is possible for lengths of up to 50 meters in the
feeding direction.
Guaranteed precision conditions:
–The cutting plotter is mounted on its stand.
–Graphtec-specified film is used with the stipulated set-
ting conditions.
Film: 3M plastic-backed film
Setting conditions: Cutter speed, 30 cm/s max; Quality, 2
4 – 27
(ENTER)
(PREV.) key.
