WEG CFW08 Vector inverter User Manual page 91

DETAILED PARAMETER DESCRIPTION
[Factory Setting]
Parameter
90
Range
Unit Description / Notes
NOTES!
1) Local/Remote = open/0V at the digital input respectively.
2) P263=0 (not used or general enable) operates as follows:
3) The programming of P265 or P266=8 (not used or start/stop)
4) The selection of P265=P266=5 (EP) requires the programming
5) The selection of P264 and/or P265 and/or P266=7 (multispeed)
6) If different acceleration and deceleration times are desired
7) See explanation about Flying Start Disable at P310 and
8) The option manual/automatic is explained in item 6.3.5 -
- if the comand source are the terminals, i.e., if P229=1
for the local mode or P230=1 for the remote mode, the DI1
operates as general enable;
- otherwise, no function is assigned to the input DI1.
operates in similar way, i.e.:
- if inverter is running in local mode and P229=1, the digital
input DI3/DI4 operates as start/stop;
- if inverter is running in remote mode and P230=1, the digital
input DI3/DI4 operates as start/stop;
- otherwise no function is associated to the input DI3/DI4.
of P221 and/or P222=4.
requires the programming of P221 and/or P222=6.
for a given operation condition (for instance for a set of
frequencies or for a direction of rotation), check if it possible
to use the multispeed function with ramp #2 and FWD/REV
with ramp #2.
P311.
Special Function Parameters (PID).
