The following entries are displayed on this screen:
Stack Config

Stack Name：
Stack Auth Mode：
Stack Auth Key:
Input Again:
Stack Priority Config

Switch#：
Role：
MAC Address:
Priority:
Stack Port Config

Stack Port：
Status:

5.1.3 Switch Renumber

In a stack system, unit number is implemented to identify and manage the member device. Unit
number is unique in a stack system. Unit number can be assigned automatically by stack system
or manually configured by users. On this page, you can configure the unit number of member
switch.
Enter the name of the stack. The length of this field should be 1-30
characters. After the stack is established, the name of master
determines the stack name.
Select the authentication mode used in stack creation. There are
three options: "None", "Simple" and "MD5".
None: Indicates no authentication mode is adopted in stack
•
creation.
Simple: Indicates simple plain text authentication mode is
•
adopted in stack creation.
MD5: Indicates MD5 authentication mode is adopted in stack
•
creation.
Enter the authentication password used in stack authentication if
the Stack Auth Mode is "Simple" or "MD5".
Retype the authentication password which should be the same
with above.
The unit number of the switch.
The role of the switch in the stack as Master or Slave.
The unique identification of the switch.
The priority for the stack member. The priority ranges from 1 to 15.
The new priority value takes effect immediately but does not affect
the current stack master. The new priority helps determine which
stack member is elected as the new stack master when the
current stack master or the switch stack resets.
Select the desired switch port. It is multi-optional.
Allows you to Enable/Disable the stack feature of the specified
port.
