Powering Up the System

Use this procedure to establish a direct cable connection between the USG and your
laptop computer, and to power up the system.
Place the USG on a flat and stable work surface.
1.
Connect the power cord.
2.
Connect the DB9 male-to-female serial cable (6 ft. length) between the USG's
3.
"serial port" and your computer.
Turn on your computer and allow it to boot up.
4.
Turn on the USG.
5.
Rear Panel
PMS port
34
G ™
ATEWAY
Connect the
power cord here
serial port subscriber network
link
activity
10/100
(on)
Connect the 6 ft.
serial cable here
Fuse holder
ON/OFF switch
Serial cable
