Nomadix Universal subscriber gateway User Manual page 222

Format for each field:
REC_NUM:
USG_ID:
PROPERTY_ID:
DATE:
TIME:
ROOM_NUM:
AMOUNT:
TRANS_TYPE:
SIGNATURE:
RESULT_VALUE:
IP:
The packet after the HTTP headers added looks like this:
XML to USG™
The USG accepts a single line of XML text in the specified format. The XML string
is a command sent by the External Server to the USG product. In this case, the
acknowledgement received from the External Server forms the command. The USG
expects the acknowledgement in the following format:
218
U
NIVERSAL
00923 (numbers only, no alpha characters)
00020b
Any regular string
03/30/2001 (mm/dd/yyyy)
23:41:38 (24 hour format)
Any regular string
234.34
PMS or CC
Encrypted signature for authentication
OK or ERROR
Standard IP address format (123.123.123.123)
S G ™
UBSCRIBER ATEWAY
