You are at this step because you want the USG to act as its own DHCP server
5.
(you did not enable the DHCP relay).
The system now displays the current status of the DHCP server (the factory
default is "enabled"). Because the server is already enabled, you are immediately
prompted for its IP address.
Enter a valid IP address for the DHCP server (this is the gateway IP that
6.
subscribers will be assigned).
Enter the DHCP subnet mask.
7.
Enter the starting and ending IP addresses for the DHCP address pool you want
8.
to use. The default is 10.0.0.12 (starting) and 10.0.0.250 (ending).
Enter a duration time (in minutes) for the DHCP lease.
9.
After assigning the DHCP lease duration time, you are prompted to reboot the
system. You should ignore this request because you will be rebooting the system
after setting up the DNS options (next procedure).
Enter (no) to bypass the boot sequence.
10. n
The existing lease pool and lease table are deleted.
S S
AMPLE CREEN
Configuration>dh
Enable/Disable DHCP Relay
Enable/Disable DHCP Server
Enter DHCP Server IP
Enter DHCP Subnet Mask
Enter DHCP Pool Start IP
Enter DHCP Pool End IP
Enter lease duration minutes
The system must be reset to function properly. Reboot? [yes/no]: n
DHCP relay
External DHCP Server ID
DHCP Server
DHCP Server IP
DHCP Subnet Mask
DHCP Pool Start IP
DHCP Pool End IP
Lease duration minutes
DHCP lease pool deleted successfully
DHCP lease table deleted successfully
The system must be rebooted to function properly!
After setting the DHCP options, the USG can issue IP addresses to any DHCP
enabled subscriber who enters the network.
Installing the USG
G ™
ATEWAY
R
ESPONSE
[disabled
[enabled
[10.0.0.1
[255.255.0.0
[10.0.0.2
[10.0.7.30
[1440
Disabled
0.0.0.0
Enabled
10.0.0.9
255.255.255.1
10.0.0.100
10.0.0.200
1200
]:
]:
]: 10.0.0.9
]: 255.255.255.1
]: 10.0.0.100
]: 10.0.0.200
]: 1200
