Final alignment (hot alignment) checks
When
After the first run
Periodically

Permitted indicator values for alignment checks

NOTICE: The specified permitted reading values are valid only at operating temperature. For cold
settings, other values are permitted. You must use the correct tolerances. Failure to do so can result in
misalignment and reduced pump reliability.
When dial indicators are used to check the final alignment, the pump and drive unit are correctly aligned
when these conditions are true:
• The total indicator runout is a maximum of 0.002 in. (0.05 mm) at operating temperature.
• The tolerance of the indicator is 0.0005 in./in. (0.0127 mm/mm) of indicator separation at operating
temperature.
Cold settings for parallel vertical alignment
Introduction
This section shows the recommended preliminary (cold) settings for electric motor-driven pumps based on
different temperatures of pumped fluid. Consult driver manufacturers for recommended cold settings for
other types of drivers such as steam turbines and engines.
Recommended settings for model HT 3196
For model HT 3196, the cold setting of parallel vertical alignment is 0.0 in. (0.0 mm) for all pump
temperatures. This is because it is center-line mounted.

Alignment measurement guidelines

Guideline
Rotate the pump coupling half and the driver coupling half
together so that the indicator rods have contact with the same
points on the driver coupling half.
Move or shim only the driver in order to make adjustments.
Make sure that the hold-down bolts for the driver feet are
tight when you take indicator measurements.
Make sure that the hold-down bolts for the driver feet are
loose before you make alignment corrections.
Check the alignment again after any mechanical adjustments.

Attach the dial indicators for alignment

You must have two dial indicators in order to complete this procedure.
1. Attach two dial indicators on the pump coupling half (X):
a) Attach one indicator (P) so that the indicator rod comes into contact with the perimeter of the
Model HT 3196 i-FRAME Installation, Operation, and Maintenance Manual
driver coupling half (Y).
This indicator is used to measure parallel misalignment.
Why
This ensures correct alignment when both the pump and the driver
are at operating temperature.
This follows the plant operating procedures.
Explanation
This prevents incorrect measurement.
This prevents strain on the piping
installations.
This keeps the driver stationary since
movement causes incorrect
measurement.
This makes it possible to move the
driver when you make alignment
corrections.
This corrects any misalignments that an
adjustment may have caused.
