ITT HT 3196 i-FRAME Installation, Operation And Maintenance Manual page 21

Nameplate field
MAT L. CONST
SER. NO.
MAX. DSGN KG/CM
20°C
Nameplate on the bearing frame
Table 7: Explanation of the nameplate on the bearing frame
Nameplate field
MOD.
SIZE
SER. NO.
LUBE
ATEX nameplate
Nameplate field
II
2
G/D
T4
NOTICE: Make sure that the code classifications on the pump are compatible with the specific
environment in which you plan to install the equipment. If they are not compatible, do not operate the
equipment and contact your ITT representative before you proceed.
Model HT 3196 i-FRAME Installation, Operation, and Maintenance Manual
Explanation
Material of which the pump is constructed
Serial number of the pump
3
@ Kilograms per cubic centimeter at 20°C
Explanation
Pump model
Size of the pump
Serial number of the pump
Lubricant, oil or grease
Explanation
Group 2
Category 2
Pump can be used when gas and dust are present
Temperature class
Product Description
19
