Maintenance

Remove the back pull-out assembly

CAUTION:
Never remove the back pull-out assembly without assistance.
1. Is your bearing frame oil lubricated?
•
•
NOTICE:
Oil analysis should be part of a preventive maintenance program that determines the cause of a
failure. Save the oil in a clean container for inspection.
66
If No: Proceed to step 2.
If Yes:
1. Remove the bearing-frame drain plug (408A) in order to drain oil from the bearing frame.
2. Replace the plug after the oil is drained.
3. Remove the oil reservoir, if equipped.
Model HT 3196 i-FRAME Installation, Operation, and Maintenance Manual
408A
