6.
Remove the remaining nut, bolt, and washers from the pump half of the coupling guard.
It is not necessary to remove the end plate from the pump side of the bearing housing. You can access
the bearing-housing tap bolts without removing this end plate if maintenance of internal pump parts
is necessary.
7.
Remove the pump half of the coupling guard:
a) Slightly spread the bottom apart.
b) Lift upwards.
1.
2.
3.
4.
42
Driver-side coupling guard
Annular
groove
Driver
4
1
3
2
Annular groove
Pump-side end plate
Driver
Pump half of the coupling guard
Model HT 3196 i-FRAME Installation, Operation, and Maintenance Manual
