Product Description
Product Description
General description HT 3196
The HT 3196 is a horizontal, centerline-mounted, overhung, open impeller, centrifugal pump. This pump
is ANSI B73.1 compliant.
The model is based on 4 drive-unit sizes and 28 hydraulic sizes.
Figure 5: HT 3196 pump
This table shows the number of hydraulic sizes available for each drive-unit size group.
Pump size group
STi
MTi
LTi
XLT-i
14
Number of hydraulic sizes
6
16
17
5
Model HT 3196 i-FRAME Installation, Operation, and Maintenance Manual
