Temperature and vibration limits
Variable
Temperature
Vibration
Battery life
The i-ALERT Condition Monitor battery is not replaceable. You must replace the entire unit once
the battery runs out of power.
The battery life is not covered as part of the standard five-year pump warranty.
This table shows the average condition monitor battery life under normal and alarm-mode operating
conditions.
Condition monitor operational state
Normal operating and environmental conditions
Alarm mode
Nameplate information
Important information for ordering
Every pump has nameplates that provide information about the pump. The nameplates are located on the
casing and the bearing frame.
When you order spare parts, identify this pump information:
• Model
• Size
• Serial number
• Item numbers of the required parts
Refer to the nameplate on the pump casing for most of the information. See Parts List for item numbers.
Nameplate types
Nameplate
Pump casing
Bearing frame
ATEX
IECEx
Model HT 3196 i-FRAME Installation, Operation, and Maintenance Manual
Description
Provides information about the hydraulic characteristics of the pump.
The formula for the pump size is: Discharge x Suction - Nominal Maximum Impeller
Diameter in inches.
(Example: 2x3-8)
Provides information about the lubrication system used.
If applicable, your pump unit might have an ATEX nameplate affixed to the pump, the
baseplate, or the discharge head. The nameplate provides information about the ATEX
specifications of this pump.
If applicable, your pump unit might have the following IECEx nameplate affixed to the
pump and/or baseplate. The nameplate provides information about the IECEx
specifications of this pump.
Limit
195°F (91°C)
100% increase over the baseline level
Battery life
Three to five years
One year
Product Description
17
