ITT HT 3196 i-FRAME Installation, Operation And Maintenance Manual page 131

Item Quantity Part name
332A 1 Outboard Labyrinth Seal w/O-rings
333A 1 Inboard Labyrinth Seal w/O-rings
351 1 Casing Gasket
353 4 Gland Stud
355 4 Gland Stud Nut
358 1 Plug—Casing Drain
358Y 1 *** Plug, Impeller
360C 1 *** Gasket—Thrust End Cover
360D 1 Gasket—Frame-to-Adapter
360Q 1 Gasket—Gland-to-Stuffing Box Cover Material varies
361A 1 Retaining Ring
370 **** Bolt—Adapter to Case
370B 4 Bolt—Frame-to-Adapter
370C ** Clamp Bolt —Bearing Housing
370D ** Jack Bolt—Bearing Housing
370F 2 Bolt—Frame Foot to Frame
370H 2 Stud—Stuffing Box Cover-to-Adapter 2228
370H 2 Bolt—Cap Casing to Support
371C 6 *** Cap Screw-End Cover to Bearing
Housing
382 1 Bearing Lockwasher
383 1 Mechanical Seal
400 1 Coupling Key
408A 1 Plug—Oil Drane
408H 4 Plug—Oil Mist Connection
408J 1 Plug—Oiler
408L 1 Plug—Oil Cooler Inlet
408M 1 Plug—Oil Cooler Outlet
408N 1 Plug—Sight Glass
412A 1 O-Ring, Graphoil Impeller
418 3 Jack Bolt—Adapter-to-Case
423 3 Jam Nut—Bearing Housing Jack Bolt 2210
423B 2 Hex Nut—Stuffing Box Cover to
Adapter
428 1 Gasket, Plug
437 1 Lockwasher, Casing to Support
458Y 1*** Plug, Impeller
469B 2 Dowel Pin—Frame-to-Adapter
494 1 Tube Element, Finned Cooled
496 1 O-Ring Bearing Housing
412A 1 O-Ring—Impeller
Model HT 3196 i-FRAME Installation, Operation, and Maintenance Manual
Parts Listings and Cross-Sectional Drawings
Pump Material
All 317SS All Monel
Brass ASTM B505-96
Brass ASTM B505-96
Aramid fiber w/EPDM
2232 2150
2232 2150
2232 2150
2232 2150
Buna
Buna
Steel
2228
2210
2210
2210
2210
– –
2210
Steel
Material varies
2210
2210
2210
2210
2210
2210
2210
– –
2228
2228
Teflon
– –
2232 2150
Steel
304SS / Copper
Buna N
Viton
All Nickel All
Hastelloy C
2155 2248
2155 2248
2156 2248
2156 2248
– 2210*
– *
– 2210*
2155 2248
All
Hastelloy B
2247
2247
2247
2156
–
–
–
2247
