Figure 3-8 Individual J4400 Power Supply; Table 3-7 J4400 Array Power Supply Components - Sun Microsystems J4200 System Overview Manual

Individual J4400 Power Supply
FIGURE 3-8
5
describes the J4400 power supply components and
TABLE 3-7
J4400 power supply status indicator descriptions.
J4400 Array Power Supply Components
TABLE 3-7
ID Component
1 Cooling fan status indicator
2 AC power status indicator
3 DC power status indicator
4 Power supply status indicator
5 Power on/off switch
6 Power cord tie wrap
Universal power input
7
connector
Right ejection arm and captive
8
screw latch
1 2 3 4
6 7 8
See
TABLE 3-8
See
TABLE 3-8
See
TABLE 3-8
See
TABLE 3-8
Turns power to the array on or off.
Holds the power cord in place.
Provides power to the array.
Secures the power supply to the
chassis.
Chapter 3
TABLE 3-8
Description
.
.
.
.
Understanding the Status Indicators
provides the
41
