FIGURE 1-3
Host or SIM
Link In
Host or SIM
Link In
Host or SIM
Link In
Host or SIM
Link In
FIGURE 1-4
4
Sun Storage J4200/J4400 Array System Overview • June 2009
J4200 Array Interconnected With Three Additional J4200s
shows a Sun Storage J4400 interconnected with other J4400 Arrays.
To Host Server
Tray 3
Tray 2
SIM Link Out
Tray 1
SIM Link Out
Tray 0
SIM Link Out
