Figure Legend
Individual J4200 Array Fan Module
FIGURE 3-10
1
Figure Legend
ID
1
Thumbscrew
2
Fan module handle
3
Bicolored (green/amber) status indicator
J4200 Fan Status Indicators
Following are the J4200 fan status indicator descriptions.
ID
Description
0
Fan module 0
1
Fan module 1
Description
Chapter 3
2
3
Understanding the Status Indicators
43
