SIM Board Status Indicators

Following are the J4200/J4400 SIM board status indicator descriptions:
J4200/J4400 Array SIM Board Status Indicator Descriptions
TABLE 3-4
ID Indicator
4 Serial
Management
Port
6 Serial
Management
Port
7 to 12 SAS Faults
13 Locate SIM
Board
14 Power SIM
Board
Color Condition
Green Serial port is
active
Amber Serial port fault Right status indicator - serial
Green/Amber Green is On
Amber is Off
Green/Amber Green is Off
Amber is On
Green/Amber Green is
Blinking
Amber is Off
Green/Amber Green is
Blinking
Amber is On
Blue On
Blue Off
Green On
Green Blinking @ 1
Hz 50%
Amber Off
Amber On
Description
Left status indicator - serial
management connector
management connector
Optimal operating status - no
activity
Link not operating
OK with activity
Link operating with fewer than
all four links
Identified as ready for service
(not supported)
Not identified
Power on and system is
operating
System is booting, being
configured, or downloading
firmware
SIM OK
SIM fault
