Figure 1-16 Individual J4400 Power Supply; Table 1-7 J4400 Array Power Supply Components - Sun Microsystems J4200 System Overview Manual

FIGURE 1-16
TABLE 1-7
J4400 power supply status indicator descriptions.
TABLE 1-7
ID
1
2
3
4
5
6
7
8
20 Sun Storage J4200/J4400 Array System Overview • June 2009
Individual J4400 Power Supply
1 2
5 6
describes the J4400 power supply components and
J4400 Array Power Supply Components
Component
Cooling fan status indicator
AC power status indicator
DC power status indicator
Power supply status indicator
Power on/off switch
Power cord tie wrap
Universal power input
connector
Right ejection arm and captive
screw latch
3 4
7 8
Description
See .
TABLE 1-8
See .
TABLE 1-8
See .
TABLE 1-8
See .
TABLE 1-8
Turns power to the array on or off.
Holds the power cord in place.
Provides power to the array.
Secures the power supply to the
chassis.
provides the
TABLE 1-8
