J4200/J4400 Array Power Supplies; Figure 3-5 J4200 Array Power Supplies - Sun Microsystems J4200 System Overview Manual

J4200/J4400 Array Power Supplies

Caution – The power supplies in this equipment can produce high energy hazards.
Only instructed personnel with authorized access to this equipment can remove and
replace modules in the system.
FIGURE 3-5
power supplies.
FIGURE 3-5
0
Figure Legend
38 Sun Storage J4200/J4400 Array System Overview • June 2009
shows J4200 array power supplies and
J4200 Array Power Supplies
ID
0
1
FIGURE 3-6
Component
Power Supply 0
Power Supply 1
shows J4400 array
1
