Table 3-1 J4200/J4400 Front Panel Status Indicators - Sun Microsystems J4200 System Overview Manual

FIGURE 3-1
Following are the
TABLE 3-1
ID
1 System Locate
System OK/
2
Fault
32 Sun Storage J4200/J4400 Array System Overview • June 2009
Indicators on the Front of a Sample J4200 Array
1
2
3
4
J4200/J4400
J4200/J4400 Front Panel Status Indicators
Indicator Color
White
White
Green
Green
Green
Amber
Amber
Array front panel status
Condition
Off Not supported
Blinking @ Location LED is active
1 Hz 50%
On System is powered on
Blinking @ System is booting or being
4 Hz 50% configured
Off System is powered off
Off No current faults
On System fault
descriptions.
indicator
Description
