TABLE 3-5
ID
1
2
3
4
5
6

J4200 Power Supply Status Indicators

Following are the J4200 power supply status indicator descriptions.
TABLE 3-6
ID Indicator
1 Power Status
2 Power Fault
40 Sun Storage J4200/J4400 Array System Overview • June 2009
J4200 Array Power Supply Components
Component
Green indicator See
TABLE 3-6
Amber See
TABLE 3-6
indicator
Universal Power cord connector.
power input
connector
Power supply Holds the power supply handle down.
latch
Power cord Holds the power cord in place.
clamp
Power supply Used to remove the power supply from and insert the
handle power supply into the J4200 enclosure.
J4200 Power Supply Status Indicators
Color Condition
Green On
Green Off
Green Blinking
Amber On
Amber Off
Description
.
.
Description
AC/DC Power Ready
No AC/DC Power Input
AC Present and Standby Output is Available
Power Supply Failure
Power Supply Healthy
