Sun Microsystems J4200 System Overview Manual page 44

TABLE 2-1
System Form Factor
Dimensions
Management Features
AC Power
Maximum Operating Current
Maximum Operating Current
Operating Environment
28 Sun Storage J4200/J4400 Array System Overview • June 2009
Sun Storage J4200/J4400 Specifications
Up to 12 (J4200) or 24 (J4400) SAS or SATA II disks
Internal bays for up to 12 disks (J4200) or 24 disks
(J4400)
Rack mount in a 19-inch cabinet
J4200 - 2 Rack Units: The chassis is 17.51 in. (445
mm) wide X 3.44 in. (87.4 mm) high X 24.05 in. (611
mm) deep (not including cables)
J4400 - 4 Rack Units: The chassis is 17.51 in. (445
mm) wide X 6.88 in. (174.8 mm) high X 23.38 in.
(594 mm) deep (not including cables)
Online software and firmware upgrades
Status indicators for SIM boards, disks, power
supplies, and fan modules
J4200: 9 A maximum operating (100 VAC to 127
VAC range), 47 to 63 Hz
4.5 A maximum operating (200 VAC to 240 VAC
range, 47 to 63 Hz
1.51 A maximum operating @ 240 VAC (198 VAC to
264 VAC range), 50 to 60 Hz
J4400: 10 A maximum operating (100 VAC to 127
VAC range), 47 to 63 Hz
2.47 A maximum operating @ 240 VAC (198 VAC
to 264 VAC range), 50 to 60 Hz
Heat output J4200: 352.8 Watts (1204 BTU/hour)
Heat output J4400: 662 Watts (2123 BTU/hour)
Temperature: 35˚ F to 95˚ F (0˚ C to 35˚ C)
maximum
Humidity: 20% to 80% (noncondensing) maximum
Altitude: 0 to 9,843 feet (3,000 meters)
Shock: 31-G +/-5%, with pulse duration of 2.6 ms
or less half-sine, bottom side tested only
Vibration: 0.25 G (peak), 3 to 200 Hz sweep @ 1/2
octave per minute, bottom side tested only
