Mode 8: Bar Code Output, When to Output, External Trigger
Polarity, Match Code, Noread Message
Mode Switches
Data Switches
Bar Code When to
Output Output
1 2
Disabled As Soon as Possible
Enabled End of Read Cycle
Mode 9: Timeout
Mode Switches
Since the number of profile card settings is limited to 255, trigger timeouts
entered from the profile card can only affect a range from 0.1 seconds to
25.5 seconds, in tenths of a second.
To set Timeout, multiply the desired number of seconds for timeout by 10
and enter the result in binary format.
See mode 1 for switch settings for timeout ranges from 0.1 seconds to 5
seconds. (Although not shown for mode 1, switches 7 and 8 are OFF for 1
through 50.) See "Binary Calculations" on page 4-13
ranges from 5.1 seconds to 25.5 seconds.
MS-3000 Single Head Decoder User's Manual
Profile Card Configuration
= On
= Off
External
Trigger Match Noread
Polarity Code Message
3 4 5
Negative Disabled Disabled
Positive Enabled Enabled
= On
= Off
for timeout
4-9
