Appendix E — Interfacing with the MS-90
This appendix describes Label Speed, a User Outputs option (see
5) that is exclusive to the MS-90 scan head.
When using a MS-90 scan
head with an MS-2000/
3000 decoder, it is neces-
sary to install MS-90 firm-
ware (35-213034-XX) that
makes Label Speed avail-
1
able.
Other than the differences
noted in this appendix,
configuration for the MS-
90 is identical to standard
single scan head configu-
ration described in this
manual.
Label Speed
Default: Medium
Options: Medium, Fast, Slow
Allows you to select a response time to match a specific label speed. For
information on navigating the menus, see
Program," on page
Format: <KYlabel speed>
label speed:
0 = Slow
1 = Medium
2 = Fast
Example: To set Label Speed to Fast, enter: <KY2>
Note: When Label Speed is set to Fast, the beeper must be disabled.
1. The MS-90 firmware does not support Aux Port, New Master Pin, Beeper Speed, or the
Microscan profile card.
MS-3000 Single Head Decoder User's Manual
Interfacing with the MS-90 Scan Head
Scan Head
CURRENT SETTINGS FOR USER OUTPUTS
BEEPER
BEEPER VOLUME
LABEL SPEED
FULL SCREENS
RELAY DRIVER
NEW MASTER PIN
GOOD/BAD POLARITY
GOOD/BAD PULSE WIDTH
ESC = MAIN MENU OR EXIT
M = PREVIOUS MENU
B = PREVIOUS ITEM
USER OUTPUTS - - > BEEPER = ON GOOD
Figure A-5 MS-90 User Outputs Menu (with
Label Speed Option)
"Using the Menu Configuration
2-2. The serial command format is explained below:
figure A-
= ON GOOD
= LEVEL 4
= MEDIUM
= ENABLED
= MISMATCH OR NOREAD
= DISABLED
= POSITIVE
= 50 ms
.
N = NEXT ITEM
SP = NEXT ITEM
CR = THIS ITEM
A-9
