Chapter 4 Profile Card Configuration

Communications Settings

Note: Changes in Communications parameters or assigning an address to
the decoder can cause loss of communications with the configuration termi-
nal when you exit the menu program (whether or not changes are saved for
power-on).
Mode 2: Address
Mode Switches
Address selection for mode 2 is identical to mode 1.
See mode 1 for switch settings.
Mode 3: Host Port Baud Rate, Parity, Stop Bits, Data Bits
Mode Switches
Data Switches
Baud Rate
1 2 3
600
1200
2400
4800
9600
19200
38400
4-6
MS-3000 Single Head Decoder User's Manual
Parity Stop Bits Data Bits
4 5 6 7
None One Seven
Even Two Eight
Odd
= On
= Off
= On
= Off
