Chapter 4 Profile Card Configuration

Summary of MS-3000 Modes

Table 4-1 Profile Card Mode Descriptions

Mode Parameter
Write-to-Device
Function
Read Function
0
Default Sets unit to the default configuration settings.
Menu Enters the menu program while decoder is in polled mode.
1 Write & Assign Address
Assign Multidrop
2
Address
Baud Rate Defines Baud Rate for the host port.
Parity Defines Parity for the host port.
3
Stop Bits Defines Stop Bits for the host port.
Data Bits Defines Data Bits for the host port.
Preamble Enables/disables Preamble.
4
Postamble Enables/disables Postamble.
Protocol Defines the communications protocol.
5
RS-422 Enables/disables RS-422.
6 Aux Port Sets Aux. Port operation mode.
Triggering Mode Defines Triggering Mode.
7
End of Read Cycle Defines End of Read Cycle.
Bar Code Output Enables/disables Bar Code Output.
When to Output Defines the conditions for When to Output.
8 External Trigger Polarity Defines External Trigger Polarity (negative/positive).
Match Code Enables/disables Match Code.
Noread Message Enables/disables Noread Message.
9 Timeout in 10 ms inc.
Serial Trigger
10
Character
11 Number of Reads Sets the number of reads for a good decode from 1-31.
Narrow Margins Enables/disables Narrow Margins for all code types.
12
Code Types Enables individual bar code types or Autodiscriminate.
Beeper Volume Sets the beeper volume.
13
Beeper Sets the conditions when the beeper is emitted.
Relay Driver Defines the mode selection for programmable output.
Full Screens Enables/disables Full Screens.
Good/Bad Polarity Sets the Polarity of output pulses.
14
New Master Pin Enables/disables New Master Pin.
Laser On/Off Enables/disables Laser On/Off.
Reverse Video Enables/disables Reverse Video.
4-2
MS-3000 Single Head Decoder User's Manual
Function
Downloads (copies) all of the configuration parameters from the
profile card to the connected decoder.
Uploads configuration data from the volatile RAM of the decoder to
the non-volatile RAM of the profile card.
Combines the write function from mode 0 with the address function of
mode 2. Downloads a multidrop address as well as all of the
configuration parameters in the profile card.
Assigns user-selected multidrop address to the decoder by using
data switches 1-6. Binary representation of the multidrop address is
used (the range is 1 to 50).
Sets the trigger timeout value. The range is 1-255 for corresponding
values of 0.1 to 25.5 seconds.
Assigns the Serial Trigger Character. (See the ASCII table on
A-3 for decimal values and corresponding characters.)
