Chapter 3 Serial Configuration
Good/Bad Polarity
Format: <Kwpolarity>
polarity:
0 = Negative
Pin 6 and 8 on host connector, and pin 2 on trigger connector.
Example: To change Good/Bad Polarity to Negative, enter <Kw0>.
Good/Bad Pulse Width
Format: <Kxrelay pulse>
duration of relay pulse:
Any number from 0 to 255.
Pin 6 and 8 on host connector, and pin 2 on trigger connector.
Example: To set Good/Bad Pulse Width to 600 ms, enter <Kx60>.
Command Start Character
Format: <KEcommand start character>
command start character:
Any ASCII character.
Example: To change Command Start Character to a colon (:), enter <KE:>.
Note: Subsequent commands must start with a colon (:). For example, enter
:D> to access the menu, or :KE<> to change back to the default character.
User Outputs Status Request
Format: <KX?>
Returns status of each command in the group.
3-16
MS-3000 Single Head Decoder User's Manual
1 = Positive
Default is 5 (50 ms).
Default is <.
