Chapter 2
Menu Configuration
End of Read Cycle
Default:
Timeout
Options: Timeout, New Trigger, Timeout & New Trigger
Allows you to choose the conditions that will end the read cycle. The read
cycle is the time during which the decoder will receive and process label
data. When the Triggering Mode option is set in an External or Serial mode
of operation, the trigger event initiates the read cycle.
Note: The Aux Port baud rate should never exceed Host Port baud rate or auxil-
iary port data could be lost.
Selecting:
Timeout
New Trigger
2-16
MS-3000 Single Head Decoder User's Manual
Has this effect:
Can end the read cycle after a specified period of time, and
if no label has been read, causes a noread message, if
enabled, to be transmitted.
With either External Edge, Serial Data, or Serial Data &
Edge enabled, a timeout ends the read cycle.
With External Level enabled, the read cycle does not end
until the falling edge trigger occurs, and the next read cycle
does not begin until the next rising edge trigger.
With Continuous Read 1 Output enabled, a timeout initiates
a new read cycle and allows the same label to be read
again.
Ends the read cycle at the occurrence of a new trigger
event, and if no label has been read, causes a noread
message, if enabled, to be transmitted at the occurrence of
the new trigger event.
With either External Edge, Serial Data, or Serial Data &
Edge enabled, an edge or serial trigger ends a read cycle
and initiates the next read cycle.
With External Level enabled, a falling edge trigger ends a
read cycle. However, the next read cycle does not begin
until the occurrence of the next rising edge trigger.
