Setting the correct label speed is important when using the MS-90 with the
MS-3000 decoder. Tables A-6 and A-7 show label speeds in inches per sec-
ond for Slow, Medium, and Fast menu label speeds for 2.5:1 ratio (as used in
Code 39) and 4:1 ratio (as used in Code 128) respectively.
In general, the medium and fast settings will correspond with the high speed
scan head and the slow setting will correspond with the low speed scan head
(for more information, see the MS-90 Scan Head User's Manual).
Table A-4 Label Speeds for Code 39 in Inches per Second
Menu Setting
SLOW:Min.
Max.
MEDIUM:Min.
Max.
FAST:Min.
Max.
Table A-5 Label Speeds for Code 128 in Inches per Second
Menu Setting
SLOW:Min.
Max.
MEDIUM:Min.
Max.
FAST:Min.
Max.
A-10
MS-3000 Single Head Decoder User's Manual
Narrow Bar Width Type
(wide-to-narrow ratio of 2.5:1)
6 mil.
7.5 mil.
10 mil.
15 mil.
0.4
0.5
0.7
1.0
10
12.9
17
25.9
2.5
3.1
4.2
6.3
57
71
95
143
18
29
30
45.6
368
460
600
600
Narrow Bar Width Type
(wide-to-narrow ratio of 2.5:1)
6 mil.
7.5 mil.
10 mil.
15 mil.
0.7
0.9
1.1
1.7
10
12.9
17
25.9
4
5
6.7
10
57
71
95
143
29
36
48
73
368
460
600
600
20 mil.
30 mil.
1.4
2.1
34
52
8.3
12.5
190
286
61
91
600
600
20 mil.
30 mil.
2.2
3.3
34
52
13.3
20
190
286
97
146
600
600
