Raster Setup Commands
Format: <KRstatus,top offset,bottom offset,motor speed>
status:
0 = Disabled
1 = Enabled
bottom offset in degrees:
Any number from
0 to 45. Default is 45.
Example: To set the raster arc to 35º and the raster motor speed to 10
sweeps per second, enter <KR1,5,40,10>.
MS-3000 Single Head Decoder User's Manual
Raster Setup Commands
top offset in degrees:
Any number from 0 to 45.
Default is 0.
motor speed (in sweeps per second):
Any number from 0 to 135. Default is 14.
3-17
