Microscan MS-3000 User Manual page 13

Chapter
1
Step 1 - Plan Scanning System............................................................1-2
Step 2 - Attach Cabling ........................................................................1-3
Step 3 - Configure Decoder................................................................1-10
Step 4 - Position Scan Head and Label .............................................1-10
Step 5 - Do Read Rate Test ...............................................................1-11
Step 6 - Install Decoder......................................................................1-12
Ground and Shield Considerations ....................................................1-14
This chapter provides step-by-step instructions for setting up and install-
ing the 3000 single head decoder.
Note: Bar code labels should meet minimum ANSI (American National
Standards Institute) standards as specified in ANSI Bar Code Print Quality
Guideline, X3.182-1990.
MS-3000 Single Head Decoder User's Manual
1
Setup and
Installation
Chapter Contents
1-1
