Microscan MS-3000 User Manual page 63

Command
Function Parameter
Ku Beeper
Kv Relay Driver Usage
Kz New Master Pin
Laser On/Off
KC
KD Reverse Video
Kw Good/Bad Polarity
Kx Good/Bad Pulse Width
KE Command Start Character
Verification Serial Command
KS
KX User Output Status Request
Raster
KR Raster Setup (1280 only)
The format for a serial configuration command is,
<Kparameterdata,data,...etc.><initializing command>
Where:
• Less than < and greater than > symbols are included as part of the com-
1
mands.
• "parameter," as used here, are those character(s) that precede the data.
• The "initializing command" <A> or <Z> is sent after configuration is com-
plete. <Z> resets and saves for power up. <A> initializes the change to
2
RAM. (For more information, see
For example, the following command enables UPC and saves the change
for power on: <Ks1><Z>.
When using serial configuration commands, note also the following conven-
tions:
• Parameters and data are "case sensitive." That is, characters must be
entered as upper or lower case, as specified.
• All data fields (except the last) must be followed by a comma (without a
space).
• If there is no change in a given field, then commas can be entered alone,
or with the existing data (for example, <Ka,,,0> or <Ka4,1,0,0>).
1. Command start character by default is a left angle bracket, <. It may be redefined by menu or serial com-
mand. However, the end character, a right angle bracket, >, cannot be changed.
2. See "Initializing serial configuration commands" on page 3-4
MS-3000 Single Head Decoder User's Manual
Format
<Kubeeper status,beeper volume,beeper speed>
<Kv mode >
<Kz status >
<KC status >
<KD status>
<Kw polarity >
<Kx number >
<KE ASCII character>
<KSserial command echo status,serial command
beep status, control/hex output>
<KX?>
<KR status,top offset,bottom offset,motor speed>
page 5-3.)
for definitions and examples.
3-3
