Pet Immunity Guidelines (EL-4755PI)
It is expected that the EL-4755PI will eliminate false alarms caused by:
• Animals up to 36kg/80lbs
• Several small rodents
• Random flying birds.
The weight of the animal should only be used as a guide, other factors such as the length
and color of fur also affect the level of immunity.
For maximum pet immunity the following guidelines are recommended:
• Mount the center of the detector at a height of 2.0m.
• Do not aim the detector at stairways that can be climbed by an animal.
• Avoid a location where an animal can come within 1.8m (6') of the detector by climbing on furniture, boxes
or other objects.
Registration Procedure
The EL-4755/4755PI must identify itself to the iConnect
1. Set the system to registration mode.
• Go to the main menu and select [9]>[1]>[1] (Programming > Devices > Zones)
• Select a zone and press '√ʹ
2. Unscrew the casing back
3. Insert the supplied batteries into their battery holders. The detector will send a transmission, which if successfully
received by the system will generate a confirmation sound. If no confirmation sound is heard, send another
transmission by pressing and releasing the tamper switch of the device.
After the detector is successfully registered the display shows: Save? Press '√ʹ to confirm and continue entering
4.
other parameters for the chosen device.
To delete a PIR detector from the system refer to the Quick Installer manual.
Parameter Setting Procedure
As a 2-Way detector, the EL-4755/4755PI parameters can be modified only from the iConnect
Go to the main menu and select [9]>[1]>[1]>[11] (Programming > Devices > Zones > Sensor Par) and define the parameters
according to the following table:
Table B- 1: Parameter Settings (EL-4755/EL-4755PI)
Sensor Par.
LED
PULSE
ALARM DELAY
CAMERA RESOLUTION
COLOR
COMPRESSION
FLASH
# OF PICTURES
PICTURE DELAY
USER MONITOR
ZONE ASSIGNMENT
*Default in bold
Web Interface Access
Transmitted pictures are visible through the web interface:
1. Access the supplied IP through your smart phone (iPhone) or web browser
2. Input access credentials
3. Click "Video" to view captured still pictures and configure settings.
82
Control System as follows
Parameter
ENABLED/DISABLED
1, 2 – The pulse counter determines the amount of beams that need to
be crossed before the sensor will produce an alarm, with 1 being more
sensitive:
1–20 minutes (3) – The delay between reporting detections to the main
unit
VGA (640X480), QVGA (320X240), QVGA (160X120)
COLOR, B&W (Black and White)
HIGH, LOW (more/less distortion)
ENABLED, DISABLED
1–9; 1–5 VGA (3)
For Future Use
0–480 MS (480)
ENABLE, DISABLE
00-00-00-000 – Movement detection in any of the up-to-four specified
zones triggers the camera to take a picture.
Appendix B: Transmitter Installation
Control System.
