1. Introduction
This manual is designed to help you install the iConnect
manual, in its entirety, before beginning the installation process so that you can best understand all that this security
system has to offer. This manual is not intended for end user use. End users are encouraged to read the user manual
provided with the system. If you have any questions concerning any of the procedures described in this manual please
contact Electronics Line 3000 Ltd. at (+972-3) 963-7777.
1.1.

Documentation Conventions

Throughout the manual, we have tried to include all of the operating and programming functions using a similar
structure and order as they appear in the menu. A detailed explanation of how to navigate the Control System's menu
is included in Menu Navigation. In order to simplify the procedures that appear in the rest of this manual, the
following conventions are used:
Table 1-1: Documentation Conventions
Item...
Select...
From the Event Log Menu, select
Clear Log.
From the Service menu, select Set
Time/Date, Set Date.
[7012]
[#5]
'√ʹ
5. Interface Test
Due to the
occurrence
The iConnect
Control System is ...
Warning ......Do not test with
flame!
The terms Control System, Control Panel, and CP refer to the same notion.
1
iConnect Installation Manual
Control System1. We strongly urge you to read through this
Description...
Use the arrow keys to scroll through the options and press '√ʹ.
Enter the main menu by pressing '√ʹand entering your user code. Using the arrow keys,
navigate until you reach Event Log and press '√ʹ. Using the arrow keys, navigate until you
reach Clear Log and press '√ʹ.
The same as above only this time you are navigating through three menu levels.
The shortcut to a specific menu item from the main menu. In this case, this is the shortcut for
Set Date. These appear in the procedures as an additional aid to menu navigation.
A shortcut to a specific item in a sub-menu. For example, [#5] is the shortcut to Bell enable
disable in the sub-menu that is opened once you have selected the detector you want to
program.
The symbol on a key that appears on the keypad
The text that actually appears on the LCD display (bold).
Important note, please pay attention.
Caution: description of a potentially hazardous situation.
Warning: description of a potentially hazardous situation that is a threat to human
life.
EN Note – restrictions and settings demanded by the standard EN 50131-1
