If the Periodic Test is disabled, the GSM RX Report feature will not function. The GSM RX
report belongs to the Peripherals event group – see p. 64, 10.9 Event Options for Central
Station Reporting. If this event group is disabled, the GSM signal strength is still recorded in
the event log.
To program the GSM RX Report option:
1. From the Programming menu, select Communications, Comm. Options, GSM Options, GSM RX Report [954121].
2. Select Enabled or Disabled.
10.7.2. PIN Code
The PIN (Personal Identity Number) is a four-digit code that protects the SIM card from unauthorized use if lost or
stolen.
When using a SIM card with an activated PIN code, the installer has to make sure that the PIN code programmed in the
Control System is the same as the SIM card's PIN code. The PIN code should be programmed in the system before
inserting the SIM card in the GSM module.
To program the PIN code:
1. From the Programming menu, select Communications, Comm. Options, GSM Options, PIN Code [954122].
2. Edit the four-digit PIN code, then press '√ʹ.
3. Power up the Control System to apply the new PIN Code definition.
The new PIN code takes effect only after the System is powered up.
If a wrong PIN code was programmed in the system, a System Trouble is generated, PIN Code Error message is
displayed, and GSM communication of any kind is not available. In this case, the SIM card must be reactivated.
To reactivate a SIM card:
1. Program the correct PIN code in the Control System (see above), then disconnect the Control System from all the
power sources.
2. Remove the SIM card from the GSM module and insert it into a cellular phone.
3. Turn on the cellular phone and enter the correct PIN code.
4. Re-install the SIM card into the Control System and apply power.
10.7.3. SMS Center
To edit the SMS Center telephone number:
1. From the Programming menu, select Communications, Comm. Options, GSM Options, SMS Center [954123].
2. Enter up to 16 digits. Use the
pulse dialing) or "+" (international code). Use the
finished.
10.7.4. SMS Command
The SMS Command option enables you to enable or disable the ability to send commands to the system via SMS. For
further information on SMS commands, see p. 18, 3.7.4 Remote Arming/Disarming via SMS and p. 33, 6.3 Telephone
Control.
To enable/disable SMS commands:
1. From the Programming menu, select Communications, Comm. Options, GSM Options, SMS Command [954124].
2. Select Enabled or Disabled.
10.7.5. SMS Confirmation
After an SMS command is executed by the system, a confirmation message is returned to the sender's mobile phone.
You can enable or disable this feature using this option.
To enable/disable SMS confirmation:
1. From the Programming menu, select Communications, Comm. Options, GSM Options, SMS Confirm [954125].
2. Select Enabled or Disabled.
62
key to enter " ", "#", "," (pause), "T" (switch to DTMF tone dialing), "P" (switch to
key to delete one character at a time. Press '√ʹ when
