Electronics Line iconnect Installation Manual

2-way wireless outdoor siren strobe
Hide thumbs Also See for iconnect:

Advertisement

Table of Contents

See also: User Manual , Installation Manual
2-Way Wireless Outdoor Siren
Strobe Installation Guide
For more detailed information please refer to the iConnect
Installer Manual provided on our website:
www.electronics-line.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the iconnect and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Electronics Line iconnect

Summary of Contents for Electronics Line iconnect

  • Page 1 2-Way Wireless Outdoor Siren Strobe Installation Guide For more detailed information please refer to the iConnect Installer Manual provided on our website: www.electronics-line.com...

  • Page 2: Table Of Contents

    Table of Contents Introduction ....................3 Location of the Siren Strobe ..............3 Mounting the Siren Strobe ................ 3 Registering the Siren Strobe ..............4 Testing the Siren Strobe ................5 Deleting a Siren Strobe ................5 Technical Specification ................6...

  • Page 3: Introduction

    1. Introduction The EL-4726 is a 2-Way Wireless Outdoor Siren Strobe for use with the iConnect 2-Way security system. In the event of an alarm the control system activates the siren and Strobe. The Wireless Siren is sounded until the end of the control-system-programmed siren cutoff.

  • Page 4: Registering The Siren Strobe

    4. Registering the Siren Strobe The EL-4726 must identify itself to the iConnect 2-Way receiver as follows: Set the system to registration mode. • Go to the main menu and select [9]>[1]>[5]>[1] (Programming > Devices > Siren>WL Siren) • Select a siren from the list (1-4) and press '√ʹ.

  • Page 5: Testing The Siren Strobe

    5. Testing the Siren Strobe Once the Siren Strobe has been registered test the unit according to the following testing procedure: To perform a Siren Strobe test Go to the main menu and select [7]>[0]>[3]>[1] (Service> Tests> WL Siren Test). Select a siren from the list (1-4) and press '√ʹ.

  • Page 6: Technical Specification

    7. Technical Specification Frequency: 868*MHz or 433MHz Power: 4 X CR123, 3V Lithium Battery ( 2 batteries for the Radio Transceiver, 2 batteries for the Speaker Current Consumption 25mA (transmission) (Radio): 40µA (standby) Current Consumption 50µA (standby) (Speaker): Maximum: 1.5A Battery Life: 3 years (typical) Siren Output:...
  • Page 7 Electronics Line Limited Warranty EL and its subsidiaries and affiliates ("Seller") warrants its products to be free from defects in materials and workmanship under normal use for 24 months from the date of production. Because Seller does not install or connect the product and because the product may be used in conjunction with products not manufactured by the Seller, Seller cannot guarantee the performance of the security system which uses this product.
  • Page 8 Contacting Electronics Line 3000 Ltd. International Headquarters: Electronics Line 3000 Ltd. 14 Hachoma St., 75655 Rishon Le Zion, Israel Tel: (+972-3) 963-7777 Fax: (+972-3) 961-6584 All rights reserved. No part of this document may be reproduced in any form without prior written permission from the publisher Electronics Line 3000 Ltd.
