Page 1: Installation Guide
2-Way Wireless Indoor Siren Installation Guide For more detailed information please refer to the iConnect Installer Manual provided on our website: www.electronics-line.com... -
Page 2: Table Of Contents
Table of Contents Introduction ....................3 Location of the Siren ................. 3 Registering the Siren ................. 3 Mounting the Siren ..................4 Testing the Siren ..................5 Deleting a Siren ..................5 Technical Specification ................6... -
Page 3: Introduction
1. Introduction The EL-4723 is a 2-Way Wireless Indoor Siren for use with the iConnect 2-Way security system. In the event of an alarm the control system activates the siren. The Wireless Indoor Siren is sounded until the end of the control-system-programmed siren cutoff. -
Page 4: Mounting The Siren
Open the housing – lift the front cover away from the rear housing. Insert the batteries while paying attention to polarity (see Figure 3-2 and Figure 3-3). Figure 3-3: Inserting the batteries #2 The Siren will send a transmission. If the transmission is successfully received by the system it will play a confirmation sound. -
Page 5: Testing The Siren
Mounting Bracket Tamper Protection Screw Figure 4-1: Attaching the mounting bracket Mount the Siren to the mounting bracket by turning the Siren clockwise. Secure the captive locking screw (see Figure 3-1) 5. Testing the Siren Once the Siren has been registered test the unit according to the following testing procedure: To perform a Siren test Go to the main menu and select [7]>[0]>[3]>[1] (Service>... -
Page 6: Technical Specification
7. Technical Specification Frequency: 868MHz or 433MHz Power: 4 X CR123, 3V Lithium Battery (2 batteries for the Radio Transceiver, 2 batteries for the Speaker) Current Consumption 25mA (transmission) (Radio): 40µA (standby) Current Consumption 50µA (standby) (Speaker): Maximum: 1.5A Battery Life: 3 years (typical) Siren Output: 105dB @ 1m... - Page 7 Electronics Line Limited Warranty EL and its subsidiaries and affiliates ("Seller") warrants its products to be free from defects in materials and workmanship under normal use for 24 months from the date of production. Because Seller does not install or connect the product and because the product may be used in conjunction with products not manufactured by the Seller, Seller cannot guarantee the performance of the security system which uses this product.
- Page 8 Contacting Electronics Line 3000 Ltd. International Headquarters: Electronics Line 3000 Ltd. 14 Hachoma St., 75655 Rishon Le Zion, Israel Tel: (+972-3) 963-7777 Fax: (+972-3) 961-6584 All rights reserved. No part of this document may be reproduced in any form without prior written permission from the publisher Electronics Line 3000 Ltd.
