Specifications - Electronics Line iconnect Installation Manual

1.2.

Specifications

General
Zones: 32 wireless zones, 2 hardwire zones (Zone 33-34), or zones 1 –
8 as wired zones, zones 9 – 32 as wireless and 2 hardwire zone (Zone
33, 34).
Wireless Keyfobs: 19 (Controlled or Non-controlled)
Wireless Keypads: up to 4
Repeaters: up to 4
Wireless
Smartkeys: 12 (Controlled or Non-controlled)
Wireless I/O Zone Expanders: 2
Wireless : up to 4
Siren
Wired Siren: 1
User Codes: 32
Arming Methods: Full, Part or Perimeter
Event Log: 1022 event capacity, time and date stamped
Weight: 1.350g
Dimensions: 270 x 222 x 50mm
Communications
Event Reporting Accounts: up to 6, including Central Station, Follow-
Me, and Voice
Telephone Numbers: 6 event reporting accounts, RP Callback,
Service Call
Communication Interface Options: GPRS/Ethernet or Ethernet/PSTN
Home Automation
Control Medium: Power-line carrier
Protocol: X10
HA Units: 16 individually addressed
Power connection to the unit should be according to the national electrical code for permanent installation.
The power supply should be fed from a readily accessible disconnect device.
If the unit is permanently wired to the mains power, use a 2-pole disconnect device (15A max.) and the wires should be min.
0.75mm in a conduit of at least 16mm.
2
If the mains power is connected with a plug, the plug should be indicated as the disconnecting device and the socket shall be
max. 2m from the Control System.
Batteries shall be provided by a distributor and replaced by authorized service personnel.
The backup battery pack should be replaced every five years.
Batteries should be stored in a cool, dry place.
*
The measurements are with fully charged battery. AC current was measured on fuse F1 and DC current was measured on fuse F2.
*
2
Receiver
Type: Super-heterodyne, fixed frequency
Frequency: 868MHz, 433MHz (optional)
SecuriCode™
Data Encryption:
Electrical*
Power Input: 230VAC, 50Hz
AC Current Consumption (GPRS Configuration): 30mA (alarm),
17mA (standby)
AC Current Consumption (Ethernet Configuration): 35mA (alarm),
17mA (standby)
DC Current Consumption (GPRS Configuration): 280mA (alarm),
130mA (standby)
DC Current Consumption (Ethernet Configuration): 330mA (alarm),
135mA (standby)
Maximum Auxiliary Output Current Rating : 50mA
Battery low: below 7.15V
Backup Battery Pack: 1 x 7.2V/1.8Ah Part No. BT5780
(6 x 1.2V Ni-MH rechargeable cells, size AA)
The maximum charging current for the BT-5780 is 5.4A
For EN-50131 standard, 1.5Ah battery is mandatory
Fuse Ratings: 63mA/250V for 230VAC – Part No. EF1063,
PGM Relay Output Contact Rating: 100mA (max. load)
Built-in Siren: 93dB @ 10ft
Tamper Switch: N.C.
Operating Temperature: 0-60°C /32-140°F
Complies with EN-50131-3 Grade 2 Class II
Power Supply Type A
