For certain versions of the iConnect
be disabled.
4.7.

Service Menu

The Service menu is accessible using either the Installer or Master code. This menu includes various functions that
enable you to test the system effectively.
4.7.1. Set Time & Date
The time and date are used to time stamp events in the event log. Additionally the time is also displayed on the LCD
display.
To set the time:
1. From the Service menu, select Set Time/Date, Set Time [7011].
2. Enter the current time.
3. Press '√ʹ; the time is modified.
To set the date:
1. From the Service menu, select Set Time/Date, Set Date [7012].
2. Enter the current date.
3. Press '√ʹ; the date is modified.
The format of the time and date is defined in the System Options – see p.48, 9.6.3 Time/Date
Format. If you are setting the time in 12hr format, use the
PM.
4.7.2. Message Center
The iConnect Control System Message Center is designed to allow the user to record a short message that may be
played back later by another user. After a message is recorded, Message Waiting is displayed on the LCD until the
message is played back. If the Vocal Message option is enabled, the Message Waiting vocal message is sounded.
Recording a new message automatically overwrites all the previous messages in the
Message Center.
To play back a recorded message:
• From the Service menu, select Messages, Play Message [7021].
To record a message:
1. From the Service menu, select Messages, Record Message [7022].
2. Press '√ʹ to start recording the message.
3. Record your message. The message may be up to twenty seconds long.
Time left out of the 20 seconds' timeout is displayed on the LCD.
4. Press '√ʹ to stop recording; the message is automatically played back and OK? Is displayed.
5. Press '√ʹ to save your recording.
The Record and Play options can also be accessed via a convenient shortcut without needing to enter a valid user code.
To play back a recorded message via a keypad shortcut:
From Standby mode, press
To record a message via a keypad shortcut:
From Standby mode, press
4.7.3. Wireless Siren Test
To test the wireless siren:
From the Service menu, select WL Siren Test [7031]; the external siren is sounded briefly.
24
Control System software, the Clear Log function may
then '√ʹ.
Χ then √. On the keypad, both LEDs flash in tandem during recording.
4 Advanced System Operation
key to toggle between AM and
